COOLANT - INTERNAL для Polaris FST IQ EURO (S07PP7FW) - 2007 года выпуска

  • №
    Артикул
    Название
  • 1
    1203065 AIRBOX ASM
    AIRBOX ASM
  • 2
    8450116-153 HOSE-.302 ID, 153 CM
    HOSE-.302 ID, 153 CM
  • 2
    7080474 CLAMP, HOSE
    CLAMP, HOSE
  • 3
    8450114-153 HOSE-.302, EPDM, 153 CM (SVC)
    HOSE-.302, EPDM, 153 CM (SVC)
  • 3
    7080003 CLAMP, HOSE
    CLAMP, HOSE
  • 4
    5249501 BRKT-IAC MOTOR
    BRKT-IAC MOTOR
  • 5
    7542122 NUT-NYLOK
    NUT-NYLOK
  • 6
    7517916 SCR-1/4-20X3/4-TR/TX/TAP-M
    SCR-1/4-20X3/4-TR/TX/TAP-M
  • 7
    1253562 ASM-IDLE AIR CONTROL MOTOR
    ASM-IDLE AIR CONTROL MOTOR
  • 8
    7517455 SCREW
    SCREW
  • 9
    5412592 HOSE-RAD/OIL COOLER, LEFT HAND
    HOSE-RAD/OIL COOLER, LEFT HAND
  • 10
    7081414 CLAMP-CONSTANT TENSION, 40-60
    CLAMP-CONSTANT TENSION, 40-60
  • 11
    5334748 TUBE-BOOST, FST
    TUBE-BOOST, FST
  • 12
    5412642 HOSE-TURBO/I.COOLER
    HOSE-TURBO/I.COOLER
  • 13
    2202945 KIT-CHARGED AIR COOLER
    KIT-CHARGED AIR COOLER
  • 13
    2202944 KIT-CAC FAN ASM
    KIT-CAC FAN ASM
  • 14
    5812870 FOAM-CAC DUCT (INCL. 14)
    FOAM-CAC DUCT (INCL. 14)
  • 15
    1240234 ASM-SHROUD, CAC, FST
    ASM-SHROUD, CAC, FST
  • 16
    5248495 BRKT-CHARGE AIR COOLER
    BRKT-CHARGE AIR COOLER
  • 17
    7661637 RIVET, INTERLOCK, Z
    RIVET, INTERLOCK, Z
  • 18
    7052028 GROMMET
    GROMMET
  • 19
    1203061 DUMP VALVE, TURBO
    DUMP VALVE, TURBO
  • 20
    7080843 CLAMP, SPRINGBAND 32/12
    CLAMP, SPRINGBAND 32/12
  • 21
    5413021 CONNECTOR-BOOST TUBE/CHG AIR
    CONNECTOR-BOOST TUBE/CHG AIR
  • 22
    7517431 SCREW
    SCREW
  • 23
    2410605 SENSOR-T-MAP
    SENSOR-T-MAP
