COOLING SYSTEM для Polaris FS IQ TOURING (S07PT7ES) - 2007 года выпуска`
-
№АртикулНазвание
-
15430743 CAP, OVERFLOWCAP, OVERFLOW
-
25810279 GASKETGASKET
-
35433774 CAP, PLUG9X (GRN), FLEX TEMPCAP, PLUG9X (GRN), FLEX TEMP
-
45436215 BOTTLE-COOLANT, FS/FSTBOTTLE-COOLANT, FS/FST
-
57512095 SCREWSCREW
-
67080807 CLAMP-HOSECLAMP-HOSE
-
77621467 RIVET, BLINDRIVET, BLIND
-
85436228 MANIFOLD-COOLANT RETURNMANIFOLD-COOLANT RETURN
-
97080844 CLAMP, SPRINGBAND 35/12, BLACKCLAMP, SPRINGBAND 35/12, BLACK
-
105412853 HOSE-FILLER/MANIFOLDHOSE-FILLER/MANIFOLD
-
117542153 NUT, NYLOK, FLANGEDNUT, NYLOK, FLANGED
-
125435196 FILLER-NECK, REMOTE, COOLANT, 2FITFILLER-NECK, REMOTE, COOLANT, 2FIT
-
131240044 CAP-PRESSURE, 13 PSICAP-PRESSURE, 13 PSI
-
147080307 CLAMP, HOSECLAMP, HOSE
-
158450115-40 HOSE-HIGH TEMP, 0.25'' I.D.40CMHOSE-HIGH TEMP, 0.25'' I.D.40CM
-
168450003-1525 LINE, FUEL, 1/4 ID (1525 CM.)LINE, FUEL, 1/4 ID (1525 CM.)
-
175412781 HOSE-RUNNING BRD/COOLANT TUBEHOSE-RUNNING BRD/COOLANT TUBE
-
187080843 CLAMP, SPRINGBAND 32/12CLAMP, SPRINGBAND 32/12
-
197080842 CLAMP, SPRINGBAND 29/12, BLACKCLAMP, SPRINGBAND 29/12, BLACK
-
215412780 HOSE-RUNNING BRD/RR COOLER, RIGHT HANDHOSE-RUNNING BRD/RR COOLER, RIGHT HAND
-
221240188 WELD-REAR COOLERWELD-REAR COOLER
-
237661637 RIVET, INTERLOCK, ZRIVET, INTERLOCK, Z
-
245412779 HOSE-RUNNING BRD/RR COOLER, LEFT HANDHOSE-RUNNING BRD/RR COOLER, LEFT HAND
-
255412785 HOSE-CTR COOLER/RUNNING BRD, LEFT HANDHOSE-CTR COOLER/RUNNING BRD, LEFT HAND
-
265412783 HOSE-ENGINE OUT/RADIATORHOSE-ENGINE OUT/RADIATOR
-
275812496 MOUNT-RADIATOR, FOAMMOUNT-RADIATOR, FOAM
-
281240149 RADIATOR ASM.RADIATOR ASM.
-
295412513 MOUNT-RADIATOR, RUBBERMOUNT-RADIATOR, RUBBER
-
301240312 COOLER-OIL, 6 PLT, W BYPASS FS/TCOOLER-OIL, 6 PLT, W BYPASS FS/T
-
315135328 RESTRICTOR-COOLANT, LONG, FS/TRESTRICTOR-COOLANT, LONG, FS/T
-
325412786 HOSE-OIL CLR OUT/COOLANT BTLEHOSE-OIL CLR OUT/COOLANT BTLE
-
335412852 CONNECTOR-TUBE/MANIFOLD COOLNTCONNECTOR-TUBE/MANIFOLD COOLNT
-
345412782 HOSE-MANIFOLD/ENGINE INHOSE-MANIFOLD/ENGINE IN
-
355412784 HOSE-RADIATOR/OIL COOLER INHOSE-RADIATOR/OIL COOLER IN
-
365334771 TUBE-GRIPPER/MANIFOLDTUBE-GRIPPER/MANIFOLD
-
375412984 HOSE-ENG OUT/CENTER COOLERHOSE-ENG OUT/CENTER COOLER
-
387081192 CLAMP-HOSE (WORM DR) 25-40MM (WORM DRIVE)CLAMP-HOSE (WORM DR) 25-40MM (WORM DRIVE)
-
392520575 WELD-COOLER, BULKHEADWELD-COOLER, BULKHEAD
-
405812845 SEAL-FRONT CLOSEOFF COOLERSEAL-FRONT CLOSEOFF COOLER
-
415135769 SLEEVE-OIL COOLERSLEEVE-OIL COOLER
