ELECTRICAL - MAGNETO ASSEMBLY W/ COIL для Polaris 120 AND EURO (S07WB1AS/AE) - 2007 года выпуска`
-
№АртикулНазвание
-
13086694 CAP, SPARKPLUGCAP, SPARKPLUG
-
23086965 COIL, IGNITIONCOIL, IGNITION
-
33083730 ASM., BOLT AND WASHERASM., BOLT AND WASHER
-
43086677 FLYWHEELFLYWHEEL
-
53085697 ASM., SCREW AND WASHERASM., SCREW AND WASHER
-
63086682 COIL, CHARGECOIL, CHARGE
-
73086688 CLAMPCLAMP
-
83086720 CLAMP, WIRECLAMP, WIRE
-
93086687 GROMMETGROMMET
-
103085359 BOLT, FLANGEBOLT, FLANGE
-
113070185 SPARK PLUG-NGK B6ESSPARK PLUG-NGK B6ES
Все узлы модели:
- CARBURETOR ASSEMBLY
- CLUTCH ASSEMBLY
- CONSOLE W/WIRE HARNESS
- CRANKCASE ASSEMBLY
- DECALS
- DRIVE TRAIN ASSEMBLY W/ DRIVE BELT
- • ELECTRICAL - MAGNETO ASSEMBLY W/ COIL
- ENGINE MOUNTING W/ SHORT BLOCK
- EXHAUST SYSTEM
- GOVERNOR
- HANDLEBAR ASSEMBLY W/ CONTROLS
- HOOD ASSEMBLY W/ WINDSHIELD
- INTAKE ASSEMBLY
- NOSEPAN ASSEMBLY
- PISTON AND CRANKSHAFT
- SEAT W/ GAS TANK ASSEMBLY
- SKI ASSEMBLY
- STARTER - RECOIL W/ BLOWER HOUSING
- SUSPENSION - FRONT W/ STEERING
- SUSPENSION - REAR
- TOOL KIT
- TUNNEL ASSEMBLY
