SUSPENSION - REAR для Polaris FS Classic (S06PD7ES) - 2006 года выпуска`
-
№АртикулНазвание
-
17547263 NUT NYLOKNUT NYLOK
-
25412616 TRACK RIP SAW (15X128'') (1.25)TRACK RIP SAW (15X128'') (1.25)
-
25222840 CLIP, GUIDECLIP, GUIDE
-
37547064 NUT, NYLOKNUT, NYLOK
-
45432535 SPACER, IDLERSPACER, IDLER
-
57555918 BUSHINGBUSHING
-
61594087 WHEEL, PLAIN ASSY (6.38 O.D)WHEEL, PLAIN ASSY (6.38 O.D)
-
75333285 SPACER, IDLER, LONGSPACER, IDLER, LONG
-
85020744 SHAFT, IDLERSHAFT, IDLER
-
91590303-244 WHEEL IDLER ASSY (SILVER METALLIC)WHEEL IDLER ASSY (SILVER METALLIC)
-
97710444 RING, RETAININGRING, RETAINING
-
93514384 BEARINGBEARING
-
107556130 WASHERWASHER
-
117517731 BOLTBOLT
-
127517896 SCREWSCREW
-
137517821 SCREWSCREW
-
147555806 WASHER, FLATWASHER, FLAT
-
157518478 SCREWSCREW
-
167552603 WASHER, SPRING LOCKWASHER, SPRING LOCK
-
177556042 WASHER, FLATWASHER, FLAT
-
185135040 BLOCK SHOCK PIVOT ADJUSTBLOCK SHOCK PIVOT ADJUST
-
197517921 SCREWSCREW
-
207517857 SCREWSCREW
-
215333902 SPACER SHOCK CENTERINGSPACER SHOCK CENTERING
-
225411965 O-RING (.875ID X .125 DIA)O-RING (.875ID X .125 DIA)
-
235132586 MOUNT LIMITER STRAP ATTACH (LOWER)MOUNT LIMITER STRAP ATTACH (LOWER)
-
245132793 SHAFT TAPEREDSHAFT TAPERED
-
255132579 SHAFT, PIVOT (LOWER)SHAFT, PIVOT (LOWER)
-
261542211 WHEEL/SPACER, BOGIE ASSY (5.62)WHEEL/SPACER, BOGIE ASSY (5.62)
-
275132490 SHAFT (.390X.750X.8665)SHAFT (.390X.750X.8665)
-
285330394 SPACER BOGIE INNERSPACER BOGIE INNER
-
297556301 BUSHINGBUSHING
-
305133093 SHAFT (LOWER)SHAFT (LOWER)
-
317558402 WASHER, FLATWASHER, FLAT
-
325333477-067 TUBE (.334X.50X8.515) (BLACK)TUBE (.334X.50X8.515) (BLACK)
