CRANKCASE ASSEMBLY для Polaris 800 RMK (S04NK6ES) - 2004 года выпуска

  • №
    Артикул
    Название
  • 1
    7080681 CLAMP, HOSE
    CLAMP, HOSE
  • 2
    7517398 SCREW
    SCREW
  • 3
    7080880 CLAMP HOSE .625 DIA VINYL COATED
    CLAMP HOSE .625 DIA VINYL COATED
  • 4
    7080683 CLAMP, HOSE
    CLAMP, HOSE
  • 5
    1253327 ADAPTER, CARBURETOR (40MM)
    ADAPTER, CARBURETOR (40MM)
  • 6
    5433151 STUFFER REED BLOCK, NOK
    STUFFER REED BLOCK, NOK
  • 7
    1201825 VALVE, REED, ASSY
    VALVE, REED, ASSY
  • 8
    5131677 STUD, CYLINDER FLANGE (152MM)
    STUD, CYLINDER FLANGE (152MM)
  • 9
    8450061-600 LINE, FUEL (3MMX7MM)
    LINE, FUEL (3MMX7MM)
  • 10
    7080603 CLAMP
    CLAMP
  • 11
    7051020 VALVE, CHECK (90 DEG)
    VALVE, CHECK (90 DEG)
  • 12
    2202336 CRANKCASE 80/70 KIT (INCL. 8, 11, 21, 22, 24, 25)
    CRANKCASE 80/70 KIT (INCL. 8, 11, 21, 22, 24, 25)
  • 13
    5411125 O-RING
    O-RING
  • 14
    5630610 MANIFOLD, WATER INLET
    MANIFOLD, WATER INLET
  • 15
    5243431 RETAINER INLET WATER MANIFOLD
    RETAINER INLET WATER MANIFOLD
  • 16
    7516736 SCREW
    SCREW
  • 17
    8450068-04 HOSE
    HOSE
  • 18
    7080560 CLAMP, HOSE
    CLAMP, HOSE
  • 19
    5411394 SEAL, FLANGED
    SEAL, FLANGED
  • 20
    7051529 PLUG
    PLUG
  • 21
    7516919 SCREW
    SCREW
  • 22
    7516732 SCREW
    SCREW
  • 23
    7710441 RING, RETAINING
    RING, RETAINING
  • 24
    7052322 FITTING
    FITTING
  • 25
    7663001 PIN, DOWEL
    PIN, DOWEL
  • 26
    7555998 WASHER, FLAT
    WASHER, FLAT
  • 27
    7052160 VALVE, CHECK
    VALVE, CHECK
  • 28
    7517319 SCREW
    SCREW
  • 29
    7080654 RETAINER
    RETAINER
