CONSOLE для Polaris 600 XC SP EDGE X F/O (S03NA6ES) - 2003 года выпуска

  • №
    Артикул
    Название
  • 2
    7541925 NUT, NYLOK
    NUT, NYLOK
  • 3
    4010793 REGULATOR - AC, 14.3V [MANUAL START)
    REGULATOR - AC, 14.3V [MANUAL START)
  • 3
    4010794 REGULATOR - AC/DC 14.3V [ELECTRIC START)
    REGULATOR - AC/DC 14.3V [ELECTRIC START)
  • 4
    7555746 WASHER
    WASHER
  • 6
    4010193 HOUSING - CONNECTOR, PAC#12186213
    HOUSING - CONNECTOR, PAC#12186213
  • 7
    4010192 SOCKET - PACKARD#12047767
    SOCKET - PACKARD#12047767
  • 8
    4020092 TERMINAL, RING
    TERMINAL, RING
  • 9
    2461116 HARNESS - MAIN, EDGE, DIAG
    HARNESS - MAIN, EDGE, DIAG
  • 10
    4020057 HOUSING
    HOUSING
  • 11
    4020063 HOUSING, PACK
    HOUSING, PACK
  • 12
    5410611 KEY
    KEY
  • 13
    7547035 NUT, IGNITION
    NUT, IGNITION
  • 14
    5432944 NUT, CHOKE
    NUT, CHOKE
  • 15
    7515199 SCREW
    SCREW
  • 17
    7080946 CABLE - CHOKE [INCL. 18, 14)
    CABLE - CHOKE [INCL. 18, 14)
  • 18
    5432943 KIT, CHOKE LEVER REPAIR [INCL. PIN)
    KIT, CHOKE LEVER REPAIR [INCL. PIN)
  • 19
    7670088 CLIP, PLASTIC DART, NYLON
    CLIP, PLASTIC DART, NYLON
  • 20
    2201614 KIT - IGNITION SWITCH, ES, FUEL
    KIT - IGNITION SWITCH, ES, FUEL
  • 22
    5434134 CONSOLE
    CONSOLE
  • 23
    7512031 SCREW [MANUAL START)
    SCREW [MANUAL START)
  • 23
    7517263 SCREW, HX/SEMS [ELECTRIC START)
    SCREW, HX/SEMS [ELECTRIC START)
  • 24
    7512050 SCREW, W/WASHER
    SCREW, W/WASHER
