SUSPENSION - SHOCK AND RESERVOIR (REAR TRACK) для Polaris 800 XC SP F/O BUILT AFTER 3/1/01 (S02NP8CS) - 2002 года выпуска`
-
№АртикулНазвание
-
1A7042093 SHOCK, REAR TRACK (REMOTERES, FOX)SHOCK, REAR TRACK (REMOTERES, FOX)
-
11500157 FITTING, ELBOW (90DEG.)FITTING, ELBOW (90DEG.)
-
21500326 HOSE, ASSY. (3.12 TLG)HOSE, ASSY. (3.12 TLG)
-
31500329 RESERVOIR ASSY. [SEE EDGE SHOCK COMPRESSION DAMPING RESERVOIR]RESERVOIR ASSY. [SEE EDGE SHOCK COMPRESSION DAMPING RESERVOIR]
-
41500256 U-CUPU-CUP
-
51500257 WIPER-U-CUPWIPER-U-CUP
-
61500302 EYELET (.88W 1.38TLG 808-05-002)EYELET (.88W 1.38TLG 808-05-002)
-
71500322 SHAFT (.62X8.35TLG, 1.15SHLG)SHAFT (.62X8.35TLG, 1.15SHLG)
-
81500328 BEARING, ASSY. QUAD RINGBEARING, ASSY. QUAD RING
-
92200618 VALVE PISTON KIT (FOX SHOCK)VALVE PISTON KIT (FOX SHOCK)
-
101500074 BUMPER, RUBBERBUMPER, RUBBER
-
111500016 NUT, LOCKNUT, LOCK
-
121500319 BODY (8.67 TLG, .58 THD)BODY (8.67 TLG, .58 THD)
-
131500108 O-RING (.103W-1.549ID)O-RING (.103W-1.549ID)
-
141500244 BODY CAP ASSY.BODY CAP ASSY.
-
151500327 SLEEVE (.385X.560X1.30)SLEEVE (.385X.560X1.30)
-
161500311 SLEEVE (.56X.81X1.28)SLEEVE (.56X.81X1.28)
-
171500307 BUSHING (.35ILG, .63TLG)BUSHING (.35ILG, .63TLG)
-
181500330 CLAMP, HOSE (3.21-3.25)CLAMP, HOSE (3.21-3.25)
