FUEL TANK для Polaris VIRAGE I (IA) - 2004 года выпуска

  • №
    Артикул
    Название
  • 1
    5244279 BRKT-STRAP, 5/16 BOLT
    BRKT-STRAP, 5/16 BOLT
  • 2
    7552610 WASHER, LOCK, S.S.
    WASHER, LOCK, S.S.
  • 3
    7515361 BOLT, S.S.
    BOLT, S.S.
  • 4
    5243775 HOOK, STRAP, NARROW
    HOOK, STRAP, NARROW
  • 5
    5430621 STRAP
    STRAP
  • 7
    5243776 HOOK, STRAP, 180 DEG RETURN
    HOOK, STRAP, 180 DEG RETURN
  • 8
    5410424 STRAP-BATTERY HOLD DOWN-C
    STRAP-BATTERY HOLD DOWN-C
  • 9
    2520177 ASM., CAP, FUEL, RATCHET
    ASM., CAP, FUEL, RATCHET
  • 10
    7080710 CHAIN, BEAD
    CHAIN, BEAD
  • 11
    7511873 SCREW
    SCREW
  • 12
    7080442 COUPLING, END
    COUPLING, END
  • 13
    5433553 INLET, FUEL
    INLET, FUEL
  • 14
    5811492 SEAL, FUEL INLET
    SEAL, FUEL INLET
  • 15
    5433621 NUT, INLET, FUEL
    NUT, INLET, FUEL
  • 16
    7080766 CLAMP, HOSE, S.S.
    CLAMP, HOSE, S.S.
  • 17
    5411757 HOSE, FUEL FILL
    HOSE, FUEL FILL
  • 18
    7080451 CLAMP, HOSE, S.S.
    CLAMP, HOSE, S.S.
  • 19
    5433259 NUT
    NUT
  • 20
    2410129 PUMP, FUEL, ELECTRIC
    PUMP, FUEL, ELECTRIC
  • 21
    5411636 GASKET
    GASKET
  • 22
    7621407 RIVET
    RIVET
  • 23
    5812206 PAD-FUEL TANK STOP, 5/16
    PAD-FUEL TANK STOP, 5/16
  • 24
    5244758 BRKT, FUEL TANK STOP
    BRKT, FUEL TANK STOP
  • 25
    5812152 PAD-EVA, 26'' X 5'' X .22
    PAD-EVA, 26'' X 5'' X .22
  • 26
    5434872 TANK-FUEL, LTR, W/RELIEF, DFI
    TANK-FUEL, LTR, W/RELIEF, DFI
  • 27
    7621229 RIVET
    RIVET
  • 28
    5411305 SEAL, FUEL CAP
    SEAL, FUEL CAP
