HANDLEBAR W/ COVER для Polaris MSX 140 (CB) - 2004 года выпуска`
-
№АртикулНазвание
-
17517520 SCREW, SS.SCREW, SS.
-
27555837 WASHER, FLAT, S.S.WASHER, FLAT, S.S.
-
37541931 NUT, HEX, S.S.NUT, HEX, S.S.
-
45433355-070 HANDLE-GRAB, BLACKHANDLE-GRAB, BLACK
-
55434516-070 PAD, HANDLE-BAR, BLACKPAD, HANDLE-BAR, BLACK
-
65432729 BLOCK, SPLIT-THROTTLEBLOCK, SPLIT-THROTTLE
-
72410343 SWITCH-START/STOPSWITCH-START/STOP
-
81821342-070 ASM-HANDLEBAR/COLUMN, BLACKASM-HANDLEBAR/COLUMN, BLACK
-
97080675 LANYARD, W/WHISTLELANYARD, W/WHISTLE
-
107518247 SCR-5/16-18X1.50, SHCP, SSSCR-5/16-18X1.50, SHCP, SS
-
117555831 WASHER, FLAT, S.S.WASHER, FLAT, S.S.
-
125410836 GROMMET, CABLEGROMMET, CABLE
-
135246810 BRACKET-GROMMETBRACKET-GROMMET
-
145246438 PLATE, TOPPLATE, TOP
-
155434771 HOUSING-STEERINGHOUSING-STEERING
-
167556262 WASHER-SHIM, 1.01X1.51X.03, SSWASHER-SHIM, 1.01X1.51X.03, SS
-
175631307 ARM, STEERINGARM, STEERING
-
187517528 SCREW, SS.SCREW, SS.
-
195434772 CLAMPCLAMP
-
205434773 ADJUSTER/MOUNTADJUSTER/MOUNT
-
217542335 NUT, HEX, S.S.NUT, HEX, S.S.
-
227547250 NUT-T, 5/16-18, SSNUT-T, 5/16-18, SS
-
235812485 PAD, FOAMPAD, FOAM
-
245434915 BUSHING, TAPERBUSHING, TAPER
-
257081136 CABLE-THROTTLECABLE-THROTTLE
-
267710426 RING, RETAINING, EXT., S.S.RING, RETAINING, EXT., S.S.
-
277555840 WASHER, FLAT, S.S.WASHER, FLAT, S.S.
-
285434913 LEVER-THROTTLE, FINGERLEVER-THROTTLE, FINGER
-
297661628 PINPIN
-
307080138 CABLE TIECABLE TIE
-
315432728 CLAMP, SPLIT-THROTTLE BLACK.CLAMP, SPLIT-THROTTLE BLACK.
-
327518151 SCR-M6X1.00X25 PH/PAN HD-SSSCR-M6X1.00X25 PH/PAN HD-SS
-
327552613 WASHER, LOCKWASHER, LOCK
-
327555836 WASHERWASHER
Все узлы модели:
- AIR INTAKE SYSTEM
- BATTERY BOX
- COOLING SYSTEM
- CRANKCASE
- CRANKSHAFT W/ PISTON
- DECALS
- DRIVE SHAFT W/ COUPLER
- ELECTRICAL BOX
- ENGINE MOUNTING W/ SHORT BLOCK
- ENHANCED STEERING PERFORMANCE
- EXHAUST SYSTEM
- FUEL TANK
- FUEL TANK
- • HANDLEBAR W/ COVER
- HULL AND BODY
- HULL AND BODY
- IGNITION COILS
- INTAKE GRATE W/ RIDE PLATE
- MANIFOLD
- OIL PUMP
- OIL TANK
- PROPULSION
- REVERSE
- SEAT
- SHROUD AND STORAGE
- STARTING MOTOR
- STEERING CABLE
- STORAGE COMPARTMENT - FRONT
- THROTTLE BODY
- TOOL KIT
- WATER SIPHON
