INTAKE GRATE W/ RIDE PLATE для Polaris MSX 110 (CB) - 2004 года выпуска
-
№АртикулНазвание
-
17517897 SCR-M5X0.8X12, PH, PN, SSSCR-M5X0.8X12, PH, PN, SS
-
27556270 WASHER-LOCK, 5MM-SSWASHER-LOCK, 5MM-SS
-
37556271 WASHER-FLAT, M5 X 10 X1-SSWASHER-FLAT, M5 X 10 X1-SS
-
42410344 ASM-PADDLE, WHEELASM-PADDLE, WHEEL
-
54010051-10 CONDUIT-CONVOLUTED, 100 CMCONDUIT-CONVOLUTED, 100 CM
-
67080138 CABLE TIECABLE TIE
-
75631598-329 PLATE-RIDE, BLACKPLATE-RIDE, BLACK
-
85631330 SCOOP-INLETSCOOP-INLET
-
95631328-067 GRATE-INLET, MACH, BLACKGRATE-INLET, MACH, BLACK
-
107556293 WASHER-FLAT, M8X16X2WASHER-FLAT, M8X16X2
-
117518119 BOLT-M8X1.25X30-HX/FL-SSBOLT-M8X1.25X30-HX/FL-SS
Все узлы модели:
- AIRBOX AND POPOFF VALVE
- BATTERY BOX
- CHAIN TENSIONER
- COOLANT BOTTLE
- COOLANT ELBOW
- COOLANT RAIL
- COOLING SYSTEM
- CRANKSHAFT AND BALANCE SHAFT
- CYLINDER
- DECALS
- DRIVE SHAFT W/ COUPLER
- ECU MOUNTING
- ELECTRICAL BOX
- ENGINE BEDPLATE
- ENGINE MOUNTING W/ SHORT BLOCK
- ENHANCED STEERING PERFORMANCE
- EXHAUST GASKETS AND HARDWARE
- EXHAUST SYSTEM
- FLYWHEEL
- FUEL RAIL
- FUEL SYSTEM
- FUEL TANK
- HULL AND BODY
- HULL AND BODY
- IGNITION COILS
- INTAKE AND THROTTLE BODY
- • INTAKE GRATE W/ RIDE PLATE
- INTERCOOLER
- MAGNETO
- OIL COOLER
- OIL FILTER
- OIL PUMP
- OIL SUMP
- OIL TANK/LINES
- PISTON AND ROD
- PPU ASM.
- PROPULSION
- REVERSE
- SEAT
- SENSORS
- SHROUD AND STORAGE
- STEERING CABLE
- STEERING CABLE ASSY.
- STORAGE COMPARTMENT - FRONT
- TOOL KIT
- TURBOCHARGER - LINES
- TURBOCHARGER - SENSORS
- VALVE COVER
- VALVE TRAIN
- VALVES
- VOLTAGE REGULATOR
- WATER PUMP
- WATER SIPHON
- WATER/HEAT EXHANGER
