BILGE PUMP для Polaris Virage i 3-Pass - 2003 года выпуска
-
№АртикулНазвание
-
17052141 ELBOWELBOW
-
27080138 CABLE TIECABLE TIE
-
38450050-26 HOSEHOSE
-
47080598 CABLE TIECABLE TIE
-
55431444-133 FITTING, THRU HULL (WHITE)FITTING, THRU HULL (WHITE)
-
65811317 GASKETGASKET
-
75411595 HOSE, CHAFE PROTECTEDHOSE, CHAFE PROTECTED
-
87080475 CLAMP, HOSECLAMP, HOSE
-
92410169 BILGE, W/CONNECTOR ASSY.BILGE, W/CONNECTOR ASSY.
-
107512056 SCREWSCREW
-
117555837 WASHER, FLATWASHER, FLAT
