FUEL TANK для Polaris Virage 3-Pass - 2003 года выпуска
-
№АртикулНазвание
-
15244279 BRACKET STRAP, BOLT (5/16)BRACKET STRAP, BOLT (5/16)
-
27552610 WASHER, LOCKWASHER, LOCK
-
37515361 BOLTBOLT
-
45243775 HOOK, STRAP NARROWHOOK, STRAP NARROW
-
55430621 STRAPSTRAP
-
65434871 TANK, OILTANK, OIL
-
75243776 HOOK, STRAP, RETURN (180 DEG)HOOK, STRAP, RETURN (180 DEG)
-
85410424 STRAP, BATTERY HOLD DOWNSTRAP, BATTERY HOLD DOWN
-
92520177 CAP, FUEL RATCHET ASSY.CAP, FUEL RATCHET ASSY.
-
107080710 CHAIN, BEADCHAIN, BEAD
-
117511873 SCREWSCREW
-
127080442 COUPLING, ENDCOUPLING, END
-
135433553 INLET, FUELINLET, FUEL
-
145811492 SEAL, FUEL INLETSEAL, FUEL INLET
-
155433621 NUT, INLET FUELNUT, INLET FUEL
-
167080766 CLAMP, HOSECLAMP, HOSE
-
175411757 HOSE, FUEL FILLHOSE, FUEL FILL
-
187080451 CLAMP, HOSECLAMP, HOSE
-
192410124 SENDER, PICKUP ASSY. (17 GAL)SENDER, PICKUP ASSY. (17 GAL)
-
207621407 RIVETRIVET
-
215812206 PAD FUEL TANK STOP (5/16)PAD FUEL TANK STOP (5/16)
-
225244758 BRACKET, FUEL TANK STOPBRACKET, FUEL TANK STOP
-
235812152 PAD EVA (26''X5''X.22)PAD EVA (26''X5''X.22)
-
245434914 TANK FUEL, W/RELIEF CARBURETOR (17 GAL)TANK FUEL, W/RELIEF CARBURETOR (17 GAL)
-
257621229 RIVETRIVET
-
265411305 SEAL, FUEL CAPSEAL, FUEL CAP
