PROPULSION для Polaris Virage 3-Pass Euro - 2003 года выпуска
-
№АртикулНазвание
-
17542455 NUT, HEXNUT, HEX
-
25244556 BRACKET, STEERING CABLE NUTBRACKET, STEERING CABLE NUT
-
35132355 STUD, MOUNT PUMPSTUD, MOUNT PUMP
-
45131573 HOUSING, PUMP W/O RING INT STUDHOUSING, PUMP W/O RING INT STUD
-
55410735 O-RINGO-RING
-
65432269 PIPE, WATER ENGINEPIPE, WATER ENGINE
-
75130983 STATOR, PUMPSTATOR, PUMP
-
85010294 SPACERSPACER
-
93514008 BEARINGBEARING
-
103610043 SEAL, BEARING STATORSEAL, BEARING STATOR
-
115010295 SPACER, IMPELLERSPACER, IMPELLER
-
125132372 IMPELLER (4.7)IMPELLER (4.7)
-
135411644 SEAL IMPELLER/SHAFTSEAL IMPELLER/SHAFT
-
145131196 EXTENSION, PUMPEXTENSION, PUMP
-
157522019 SCREWSCREW
-
165630598 RUBBER, BUSHINGRUBBER, BUSHING
-
175132111 STUD, MOUNT PUMP LONG INT.STUD, MOUNT PUMP LONG INT.
-
187555966 WASHERWASHER
-
197552607 WASHER, LOCKWASHER, LOCK
-
207542454 NUT, HEXNUT, HEX
-
215410817 O-RINGO-RING
-
225811984 SEAL, TAILCONESEAL, TAILCONE
-
235431523 SCREEN, ENGINE INLETSCREEN, ENGINE INLET
-
245130999 NOZZLE, STEERINGNOZZLE, STEERING
-
257515366 BOLTBOLT
-
265130938 COLLARCOLLAR
-
277552610 WASHER, LOCKWASHER, LOCK
-
287555835 WASHER, FLATWASHER, FLAT
-
295431518 BEARING, STEERING NOZZLEBEARING, STEERING NOZZLE
-
307515389 BOLTBOLT
-
315131569 NOZZLE, STATERNOZZLE, STATER
-
325432841 WEDGE, PUMPWEDGE, PUMP
-
337512064 SCREWSCREW
-
345431519 CONE, PUMPCONE, PUMP
-
355410819 O-RINGO-RING
-
365132674 SHAFT, STUBSHAFT, STUB
-
375410818 O-RINGO-RING
