ELECTRICAL BOX для Polaris MSX 140 (CB) - 2003 года выпуска
-
№АртикулНазвание
-
14010859 FUSE-15AMP, MINI BLADEFUSE-15AMP, MINI BLADE
-
24010752 FUSE-2AMP, ATM, BLADE STYLE, MINIFUSE-2AMP, ATM, BLADE STYLE, MINI
-
32461024 HARNESS-WIRE, DOORHARNESS-WIRE, DOOR
-
42461195 HARNESS-ENGINE (SEE NOTE)HARNESS-ENGINE (SEE NOTE)
-
55411598 BOOT-DFI CAPACITORBOOT-DFI CAPACITOR
-
64010198 HARNESS, ASM, 3 CYL FFIHARNESS, ASM, 3 CYL FFI
-
75410346 INSUL.CABLE SOL.INSUL.CABLE SOL.
-
87546705 NUT, 6 MM., S.S.NUT, 6 MM., S.S.
-
97552613 WASHER, LOCKWASHER, LOCK
-
104010237 CABLE-SOLENOID/STARTERCABLE-SOLENOID/STARTER
-
117556261 WASHER-LOCK, M6, EXTERNAL, SSWASHER-LOCK, M6, EXTERNAL, SS
-
124011043 SOLENOID-STARTER, WATERPRF, DIODSOLENOID-STARTER, WATERPRF, DIOD
-
134010642 CABLE-SOLENOID/STARTER 37.5CABLE-SOLENOID/STARTER 37.5
-
147621485 RIVETRIVET
-
157555837 WASHER, FLAT, S.S.WASHER, FLAT, S.S.
-
167080138 CABLE TIECABLE TIE
-
175521287-18 CONDUIT, FLEX, 1.250IDCONDUIT, FLEX, 1.250ID
-
182520337 ASM-VELCRO STRAP, EMMASM-VELCRO STRAP, EMM
-
194010973 EMM-PROGRAMMED H03EMM-PROGRAMMED H03
Все узлы модели:
- AIR INTAKE SYSTEM
- BATTERY BOX
- COOLING SYSTEM
- CRANKCASE
- CRANKSHAFT W/ PISTON
- DECALS
- DRIVE SHAFT W/ COUPLER
- • ELECTRICAL BOX
- ENGINE MOUNTING W/ SHORT BLOCK
- ENHANCED STEERING PERFORMANCE
- EXHAUST SYSTEM
- FUEL SYSTEM
- FUEL TANK
- HANDLEBAR W/ COVER
- HULL AND BODY - FOOTWELL PADS
- HULL AND BODY - HOOKS
- INTAKE GRATE W/ RIDE PLATE
- MANIFOLD/IGNITION
- OIL PUMP
- OIL TANK
- PROPULSION
- REVERSE
- SEAT
- SHROUD AND STORAGE
- STARTING MOTOR
- STEERING CABLE
- STORAGE COMPARTMENT - FRONT
- THROTTLE BODY
- TOOL KIT
- WATER SIPHON
