DRIVE SHAFT W/ COUPLER для Polaris Genesis i 4-Pass - 2003 года выпуска

  • №
    Артикул
    Название
  • 1
    1013544 DRIVE COUPLER ASSY.
    DRIVE COUPLER ASSY.
  • 2
    5410735 O-RING
    O-RING
  • 3
    7079119 DECAL, COUPLER NOTE
    DECAL, COUPLER NOTE
  • 4
    5412322 GROMMET
    GROMMET
  • 5
    7080598 CABLE TIE
    CABLE TIE
  • 6
    5812490 BRACKET, SHROUD
    BRACKET, SHROUD
  • 7
    7080870 CLAMP, HOSE
    CLAMP, HOSE
  • 8
    5133375 BUMPER, DRIVE SHAFT PLASTIC
    BUMPER, DRIVE SHAFT PLASTIC
  • 9
    6230216 SHAFT, DRIVE
    SHAFT, DRIVE
  • 10
    5410663 BUMPER, DRIVE SHAFT
    BUMPER, DRIVE SHAFT
  • 11
    5431985 NUT, SHAFT HOUSING
    NUT, SHAFT HOUSING
  • 12
    5432298 HOUSING, SHAFT THRU HULL O-RING
    HOUSING, SHAFT THRU HULL O-RING
  • 13
    7080870 CLAMP, HOSE
    CLAMP, HOSE
  • 14
    5411805 HOSE, BEARING HOUSING
    HOSE, BEARING HOUSING
  • 15
    3610040 SEAL
    SEAL
  • 16
    1341417 BEARING HOUSING ASSY. (INCL. 15, 17)
    BEARING HOUSING ASSY. (INCL. 15, 17)
  • 17
    7080629 FITTING, LUBE
    FITTING, LUBE

Все узлы модели:
