OIL TANK для Polaris Genesis i 4-Pass Euro - 2003 года выпуска
-
№АртикулНазвание
-
17080442 COUPLING, ENDCOUPLING, END
-
27080710 CHAIN, BEADCHAIN, BEAD
-
37621229 RIVETRIVET
-
47517241 SCREWSCREW
-
55432843 CAP, OILTANKCAP, OILTANK
-
67661042 RIVET, POPRIVET, POP
-
75433914 INLET, OILINLET, OIL
-
85811554 GASKET, OIL INLETGASKET, OIL INLET
-
97080481 CLAMP, HOSECLAMP, HOSE
-
107052130 ELBOW, 90 DEGREEELBOW, 90 DEGREE
-
112410131 SENDER ASSY., OIL LEVELSENDER ASSY., OIL LEVEL
-
127080138 CABLE TIECABLE TIE
-
134010051-36 CONDUITCONDUIT
-
147080307 CLAMP, HOSECLAMP, HOSE
-
155521609 HOSE (OPT)HOSE (OPT)
-
162530015 FILTER, OILFILTER, OIL
-
177080474 CLAMP, HOSECLAMP, HOSE
-
188450059-150 FUEL LINE (OPT)FUEL LINE (OPT)
-
195434871 TANK, OIL W/ RELIEFTANK, OIL W/ RELIEF
-
207052118 VALVE, VACUUM CHECKVALVE, VACUUM CHECK
-
215521608 HOSE (OPT)HOSE (OPT)
-
225412098 HOSE, FILL OILHOSE, FILL OIL
