COOLING SYSTEM для Polaris Freedom 3-Pass Euro - 2003 года выпуска
-
№АртикулНазвание
-
17080475 CLAMP, HOSECLAMP, HOSE
-
25431444-133 FITTING, THRU HULL (WHITE)FITTING, THRU HULL (WHITE)
-
35811317 GASKETGASKET
-
45521287-45 CONDUIT, FLEXCONDUIT, FLEX
-
55411049 HOSE, PUMP OUTLETHOSE, PUMP OUTLET
-
65431784 FITTING, TEEFITTING, TEE
-
77080476 CLAMP, HOSECLAMP, HOSE
-
87052128 FITTING, SCREENFITTING, SCREEN
-
98450054-100 HOSE, WATERHOSE, WATER
-
105020747 FITTING, INJECTORFITTING, INJECTOR
-
115411050 HOSE, INLETHOSE, INLET
-
127080138 CABLE TIECABLE TIE
-
137516727 BOLTBOLT
-
147516725 BOLTBOLT
-
151260694-329 MANIFOLD, EXHAUST ASSY. (BLACK)MANIFOLD, EXHAUST ASSY. (BLACK)
-
167555856 WASHER, FLATWASHER, FLAT
-
177552611 WASHER, LOCKWASHER, LOCK
-
187517004 BOLTBOLT
-
195020746 FITTING, DRAINFITTING, DRAIN
-
205521398-13 CONDUIT, FLEXCONDUIT, FLEX
-
215411479 HOSE, WATER OUT (3/4 ID.)HOSE, WATER OUT (3/4 ID.)
-
225432799 VALVE, POP OFFVALVE, POP OFF
-
237051008 THERMOSTAT (143 F.)THERMOSTAT (143 F.)
-
245412014 GASKET, THERMOSTATGASKET, THERMOSTAT
-
257556174 WASHER, ANODIZEWASHER, ANODIZE
-
265631136 COVER, THERMOSTATCOVER, THERMOSTAT
-
277041310 SPRING, COMPRESSIONSPRING, COMPRESSION
-
285410860 SEAL, O-RING/THERMO/FITTINGSEAL, O-RING/THERMO/FITTING
Все узлы модели:
- AIR INLET - ENGINE AND HULL
- BATTERY BOX
- BILGE PUMP
- CARBURETOR
- • COOLING SYSTEM
- CRANKCASE
- CRANKSHAFT W/ PISTONS
- CYLINDER W/ INTAKE
- DECALS
- DRIVE SHAFT W/ COUPLER
- ELECTRICAL BOX
- ELECTRICAL BOX
- ENGINE FOGGING SYSTEM
- ENGINE MOUNTING W/ SHORT BLOCK
- EXHAUST SYSTEM
- FUEL / WATER SEPARATOR
- FUEL SYSTEM
- FUEL TANK
- HANDLEBAR ASSY. W/ STEERING COLUMN
- HULL
- INTAKE GRATE W/ RIDE PLATE
- MAGNETO
- OIL PUMP
- OIL TANK
- PROPULSION
- SEAT
- SHROUD W/ INSTRUMENTS AND MIRRORS
- STARTING MOTOR
- STEERING CABLE ASSY.
- STORAGE COMPARTMENT - FRONT
- TOOL KIT
