FUEL TANK для Polaris Virage TX 3-Pass Euro - 2002 года выпуска`
-
№АртикулНазвание
-
15244279 BRACKET, STRAP 5/16 BOLTBRACKET, STRAP 5/16 BOLT
-
27552610 WASHER, LOCKWASHER, LOCK
-
37515361 BOLTBOLT
-
45243775 HOOK, STRAP NARROWHOOK, STRAP NARROW
-
55430621 STRAPSTRAP
-
65434542 TANK, OILTANK, OIL
-
75243776 HOOK, STRAP 180 DEG RETURNHOOK, STRAP 180 DEG RETURN
-
85410424 STRAP, BATTERY HOLDDOWNSTRAP, BATTERY HOLDDOWN
-
92520177 CAP, FUEL RATCHET ASSY.CAP, FUEL RATCHET ASSY.
-
107080710 CHAIN, BEADCHAIN, BEAD
-
117511873 SCREWSCREW
-
127080442 COUPLING, ENDCOUPLING, END
-
135433553 INLET, FUELINLET, FUEL
-
145811492 SEAL, FUEL INLETSEAL, FUEL INLET
-
155433621 NUT, INLET FUELNUT, INLET FUEL
-
167080766 CLAMP, HOSECLAMP, HOSE
-
175411757 HOSE, FUEL FILLHOSE, FUEL FILL
-
187080451 CLAMP, HOSECLAMP, HOSE
-
192410124 SENDER, PICKUP ASSY. (17 GAL)SENDER, PICKUP ASSY. (17 GAL)
-
207621407 RIVETRIVET
-
215812206 PAD, FUEL TANK STOPPAD, FUEL TANK STOP
-
225244758 BRACKET, FUEL TANK STOPBRACKET, FUEL TANK STOP
-
235433018 TANK, FUEL (16 GAL)TANK, FUEL (16 GAL)
-
245812152 PAD, EVAPAD, EVA
-
257621229 RIVETRIVET
-
265411305 SEAL, FUEL CAPSEAL, FUEL CAP
