SHROUD W/ INSTRUMENTS AND MIRRORS для Polaris Virage i 3-Pass Euro - 2002 года выпуска

  • №
    Артикул
    Название
  • 1
    3280365 GAUGE MFI RVS RPM LIMIT
    GAUGE MFI RVS RPM LIMIT
  • 2
    5411738 GASKET, MFI
    GASKET, MFI
  • 3
    8450070-190 PITOT LINE, FORMED (90 DEG) (345 CM)
    PITOT LINE, FORMED (90 DEG) (345 CM)
  • 4
    7041931 SPRING, MOUNTING MFI
    SPRING, MOUNTING MFI
  • 5
    2201593 MFI, BUTTON REPLACEMENT KIT
    MFI, BUTTON REPLACEMENT KIT
  • 6
    3280342 BEZEL MFI, OVERLAY
    BEZEL MFI, OVERLAY
  • 7
    2653011 LATCH ASSY., CONSOLE
    LATCH ASSY., CONSOLE
  • 8
    5434564-1132 LID CONSOLE, PUSH SOLAR (RED)
    LID CONSOLE, PUSH SOLAR (RED)
  • 9
    7042007 SPRING TORTION
    SPRING TORTION
  • 10
    5521596 SEAT LID, PORON
    SEAT LID, PORON
  • 11
    7546705 NUT (6 MM)
    NUT (6 MM)
  • 12
    5812235 PAD
    PAD
  • 13
    7546704 NUT, NYLOK
    NUT, NYLOK
  • 14
    7556094 WASHER
    WASHER
  • 15
    5245455 HOOK, LATCH
    HOOK, LATCH
  • 16
    7517669 SCREW
    SCREW
  • 17
    7517668 SCREW
    SCREW
  • 18
    7556055 WASHER, LOCK
    WASHER, LOCK
  • 19
    7555831 WASHER, FLAT
    WASHER, FLAT
  • 20
    5411557 GASKET MIRROR (LEFT)
    GASKET MIRROR (LEFT)
  • 20
    5411558 GASKET MIRROR (RIGHT)
    GASKET MIRROR (RIGHT)
  • 21
    2631972-070 MIRROR ASSY. (LEFT/BLACK) [INCL. 20]
    MIRROR ASSY. (LEFT/BLACK) [INCL. 20]
  • 21
    2631973-070 MIRROR ASSY. (RIGHT/BLACK) [INCL. 20]
    MIRROR ASSY. (RIGHT/BLACK) [INCL. 20]
  • 22
    7546804 NUT, HEX NYLOK
    NUT, HEX NYLOK
  • 23
    5411674 GROMMET ACCESS
    GROMMET ACCESS
  • 24
    5245934 BRACKET, EMM TOP DECK OFFSET (STD)
    BRACKET, EMM TOP DECK OFFSET (STD)
  • 25
    1821213 WELD ASSY., DOOR LATCH POST
    WELD ASSY., DOOR LATCH POST
  • 26
    7555835 WASHER, FLAT
    WASHER, FLAT
  • 27
    7517539 SCREW
    SCREW
  • 28
    7547187 NUT
    NUT
  • 29
    5132781 PIN, LATCH
    PIN, LATCH
  • 30
    5411664 GROMMET DECK, WIRE HARNESS
    GROMMET DECK, WIRE HARNESS
  • 31
    7080138 CABLE TIE
    CABLE TIE
  • 32
    5812284 COVER SHROUD (FRONT)
    COVER SHROUD (FRONT)
  • 33
    7511873 SCREW
    SCREW
  • 34
    7555837 WASHER, FLAT
    WASHER, FLAT
  • 35
    7621220 RIVET, POP
    RIVET, POP
  • 36
    5245451 BRACKET SHROUD COVER, MFI
    BRACKET SHROUD COVER, MFI
  • 37
    7516805 SCREW
    SCREW
  • 38
    7552613 WASHER, LOCK
    WASHER, LOCK
  • 39
    7556094 WASHER
    WASHER
  • 40
    5434561-1132 SHROUD STEERING, W/RVS (SOLAR RED)
    SHROUD STEERING, W/RVS (SOLAR RED)
  • 41
    5812076 BUMPER, DOOR/SHROUD
    BUMPER, DOOR/SHROUD
  • 42
    5333698 PIN, HINGE
    PIN, HINGE
  • 43
    5433384 HINGE, PIN
    HINGE, PIN
