ENGINE MOUNTING W/ SHORT BLOCK для Polaris Genesis i 4-Pass Euro - 2002 года выпуска

  • №
    Артикул
    Название
  • 1
    7515149 SCREW, SHOULDER
    SCREW, SHOULDER
  • 2
    7077026 DECAL, SPARKPLUG
    DECAL, SPARKPLUG
  • 3
    3070189 PLUG, SPARK
    PLUG, SPARK
  • 4
    7075383 DECAL, WARNING
    DECAL, WARNING
  • 5
    7556184 WASHER, FLAT
    WASHER, FLAT
  • 6
    5631166-329 PLATE MOUNT W/ WASHER (BLACK/ FRONT)
    PLATE MOUNT W/ WASHER (BLACK/ FRONT)
  • 7
    7556170 WASHER, FLAT
    WASHER, FLAT
  • 8
    5245460 LOCK, MOUNT PLATE
    LOCK, MOUNT PLATE
  • 9
    7517330 SCREW
    SCREW
  • 10
    5631167-329 PLATE, MOUNT W/ WASHER (BLACK/ REAR)
    PLATE, MOUNT W/ WASHER (BLACK/ REAR)
  • 11
    3021253 MOUNT, ENGINE
    MOUNT, ENGINE
  • 12
    5211727 SHIM, ENGINE MOUNT (OPT)
    SHIM, ENGINE MOUNT (OPT)
  • 13
    7552610 WASHER, LOCK
    WASHER, LOCK
  • 14
    7515365 BOLT
    BOLT
  • 15
    7555848 WASHER, FLAT
    WASHER, FLAT
  • 16
    7542725 NUT, NYLOK
    NUT, NYLOK
  • 17
    7556055 WASHER, LOCK
    WASHER, LOCK
  • 18
    7517497 BOLT
    BOLT
  • 19
    2201705 SHORT BLOCK KIT (BLACK) (SEE FOOTNOTE)
    SHORT BLOCK KIT (BLACK) (SEE FOOTNOTE)
  • 20
    5244176 CLIP, RETAINER, TEMP SWITCH
    CLIP, RETAINER, TEMP SWITCH
  • 21
    7516603 BOLT
    BOLT
  • 22
    2410125 SENSOR, WATER TEMP
    SENSOR, WATER TEMP
