OIL TANK для Polaris Virage TXi 3-Pass - 2001 года выпуска`
-
№АртикулНазвание
-
15432843 CAP, OILTANKCAP, OILTANK
-
27661042 RIVET, POPRIVET, POP
-
35433914 INLET, OILINLET, OIL
-
45811554 GASKET, OIL INLETGASKET, OIL INLET
-
57080481 CLAP, HOSECLAP, HOSE
-
67052130 ELBOW, 90 DEG.ELBOW, 90 DEG.
-
72410131 SENDER ASSY., OIL LEVELSENDER ASSY., OIL LEVEL
-
87080138 CABLE TIECABLE TIE
-
94010051-30 CONDUIT, CONVOL (30 CM)CONDUIT, CONVOL (30 CM)
-
108450003-1525 FUEL LINE (1/4 ID, 1525 CM.) (OPT)FUEL LINE (1/4 ID, 1525 CM.) (OPT)
-
117080307 CLAMP, HOSECLAMP, HOSE
-
122530015 FILTER, OILFILTER, OIL
-
137080474 CLAMP, HOSECLAMP, HOSE
-
148450059-150 FUEL LINE (OPT)FUEL LINE (OPT)
-
155433083 TANK, OIL W/RELIEFTANK, OIL W/RELIEF
-
167052118 VALVE, VACUUM CHECKVALVE, VACUUM CHECK
-
177080483 CABLE, TIE (4 IN.)CABLE, TIE (4 IN.)
-
185411756 HOSE, OIL FILLHOSE, OIL FILL
-
197621229 RIVETRIVET
-
207080710 CHAIN, BEADCHAIN, BEAD
-
217080442 COUPLING, ENDCOUPLING, END
-
227517241 SCREWSCREW
