TRIM ASSY. для Polaris PRO 785 2-Pass Euro - 2000 года выпуска
-
№АртикулНазвание
-
17512052 SCREWSCREW
-
25431551 COVER, TRIM METERCOVER, TRIM METER
-
37511873 SCREWSCREW
-
42460635 HARNESS, TRIM 2HOLE GROMMETHARNESS, TRIM 2HOLE GROMMET
-
55630798 BASE, MOTORBASE, MOTOR
-
65131050 STUDSTUD
-
77511872 SCREWSCREW
-
85810818 GASKET, MOTOR BASEGASKET, MOTOR BASE
-
93610042 SEAL, OILSEAL, OIL
-
107541931 NUT, HEXNUT, HEX
-
117555839 WASHER, FLATWASHER, FLAT
-
127542133 NUT, NYLOKNUT, NYLOK
-
135224670 LINKAGE, THREADEDLINKAGE, THREADED
-
147661010 PIN, COTTERPIN, COTTER
-
157555866 WASHERWASHER
-
165131463 SWIVEL, ROD ENDSWIVEL, ROD END
-
175431765 NOZZLE, TRIMNOZZLE, TRIM
-
185130938 COLLARCOLLAR
-
197515361 BOLTBOLT
-
207555874 WASHER, FLATWASHER, FLAT
-
211860102 NUTNUT
-
227512041 BOLTBOLT
-
237555837 WASHER, FLATWASHER, FLAT
-
247060154 ROD ENDROD END
-
255432551 LEVER, TRIM HEADLEVER, TRIM HEAD
-
267041469 SPRING, TRIM HEAVYSPRING, TRIM HEAVY
-
277661646 PIN, DRIVEPIN, DRIVE
-
285410756 O-RING, METER COVERO-RING, METER COVER
-
294170018 GEARMOTOR ASSY., 6 RPMGEARMOTOR ASSY., 6 RPM
