SEAT для Polaris PRO 1200 2-Pass Euro - 2000 года выпуска`
-
№АртикулНазвание
-
1A2200891 DECAL APPLIC., VINYL KIT (FOR SEAT DECAL)DECAL APPLIC., VINYL KIT (FOR SEAT DECAL)
-
17078541-133 DECAL, SEAT ''POLARIS''DECAL, SEAT ''POLARIS''
-
27542133 NUT, NYLOKNUT, NYLOK
-
37555836 WASHERWASHER
-
47547105 NUT, NYLOKNUT, NYLOK
-
55521457 BUMPER, SEATBUMPER, SEAT
-
67621403 BLIND RIVETBLIND RIVET
-
75431358 HANDLE, SEAT BASE LATCHHANDLE, SEAT BASE LATCH
-
87515123 BOLTBOLT
-
97555838 WASHER, LOCKWASHER, LOCK
-
107555839 WASHER, FLATWASHER, FLAT
-
115431357 PLATE, LATCH SEAT BASE (BOTTOM)PLATE, LATCH SEAT BASE (BOTTOM)
-
125211314 PLATE, SEATBASE LATCHPLATE, SEATBASE LATCH
-
137042036 SPRING, SEATBASE LATCHSPRING, SEATBASE LATCH
-
145431359 PLATE, SEATBASE LATCH (TOP)PLATE, SEATBASE LATCH (TOP)
-
155521429 SEAL, SEAT 1 PCSEAL, SEAT 1 PC
-
165521424 TRIM, SEAT 1 PCTRIM, SEAT 1 PC
-
175432717 FOAMFOAM
-
182682544-303 SEAT, 1 PC ASSY. (BLACK)SEAT, 1 PC ASSY. (BLACK)
-
182682333-303 COVER, SEAT 1 PC (BLACK)COVER, SEAT 1 PC (BLACK)
Все узлы модели:
- AIR INTAKE SYSTEM
- BATTERY BOX
- BILGE PUMP
- BILGE SIPHON
- CARBURETOR
- COOLING SYSTEM
- CRANKCASE
- CRANKSHAFT W/ PISTONS
- CYLINDER W/ INTAKE
- DECALS
- DRIVE SHAFT W/ COUPLER
- ELECTRICAL BOX
- ENGINE FOGGING SYSTEM
- ENGINE MOUNTING W/ SHORT BLOCK
- EXHAUST SYSTEM
- FUEL / WATER SEPARATOR
- FUEL SYSTEM
- FUEL TANK
- HANDLEBAR ASSY. W/ STEERING COLUMN
- HULL
- HULL
- INTAKE GRATE W/ RIDE PLATE
- MAGNETO
- OIL PUMP
- OIL TANK
- PROPULSION
- • SEAT
- STARTING MOTOR
- STEERING CABLE ASSY.
- STORAGE COMPARTMENT - FRONT
- TOOL KIT
- TRIM ASSY.
