ENGINE MOUNTING W/ SHORT BLOCK для Polaris PRO 1200 2-Pass Euro - 2000 года выпуска`
-
№АртикулНазвание
-
12410187 SWITCH, TEMP W/CONNECTORSWITCH, TEMP W/CONNECTOR
-
27077026 DECAL, SPARKPLUG REC.DECAL, SPARKPLUG REC.
-
35242476 GROUND, SPARKPLUGGROUND, SPARKPLUG
-
47515149 SCREW, SHOULDERSCREW, SHOULDER
-
55830051 GASKET, EXHAUST PIPEGASKET, EXHAUST PIPE
-
67075383 DECAL, WARNINGDECAL, WARNING
-
75630585 PLATE, W/WASHER KIT (FRONT)PLATE, W/WASHER KIT (FRONT)
-
87552609 WASHER, LOCKWASHER, LOCK
-
97517330 SCREWSCREW
-
105630584 PLATE, W/WASHER KIT (REAR)PLATE, W/WASHER KIT (REAR)
-
113021102 MOUNT, ENGINEMOUNT, ENGINE
-
125211727 SHIM, ENGINEMT (OPT)SHIM, ENGINEMT (OPT)
-
137555835 WASHER, FLATWASHER, FLAT
-
147552610 WASHER, LOCKWASHER, LOCK
-
157517627 SCREWSCREW
-
167555848 WASHER, FLATWASHER, FLAT
-
177542725 NUT, NYLOKNUT, NYLOK
-
187556055 WASHER, LOCKWASHER, LOCK
-
197517497 BOLTBOLT
-
202201704 SHORTBLOCK (SEE FOOTNOTE)SHORTBLOCK (SEE FOOTNOTE)
-
215240876 CLIP, RETAINER TEMP. SW.CLIP, RETAINER TEMP. SW.
-
227516603 BOLTBOLT
Все узлы модели:
- AIR INTAKE SYSTEM
- BATTERY BOX
- BILGE PUMP
- BILGE SIPHON
- CARBURETOR
- COOLING SYSTEM
- CRANKCASE
- CRANKSHAFT W/ PISTONS
- CYLINDER W/ INTAKE
- DECALS
- DRIVE SHAFT W/ COUPLER
- ELECTRICAL BOX
- ENGINE FOGGING SYSTEM
- • ENGINE MOUNTING W/ SHORT BLOCK
- EXHAUST SYSTEM
- FUEL / WATER SEPARATOR
- FUEL SYSTEM
- FUEL TANK
- HANDLEBAR ASSY. W/ STEERING COLUMN
- HULL
- HULL
- INTAKE GRATE W/ RIDE PLATE
- MAGNETO
- OIL PUMP
- OIL TANK
- PROPULSION
- SEAT
- STARTING MOTOR
- STEERING CABLE ASSY.
- STORAGE COMPARTMENT - FRONT
- TOOL KIT
- TRIM ASSY.
