PRIMARY DRIVE для Polaris HARDBALL - 2012 года выпуска

‹-+›

№

Артикул

Название
1

6230440 GEAR, BALANCE SHAFT, DRIVEN

GEAR, BALANCE SHAFT, DRIVEN
2

7042096 SPRING, SPLIT GEAR

SPRING, SPLIT GEAR
3

6230470 GEAR, SPLIT, BALANCE SHAFT, DRIVEN

GEAR, SPLIT, BALANCE SHAFT, DRIVEN
4

7710529 RING, RETAINING

RING, RETAINING
5

1332830 ASM., SPLIT GEAR (INCL. 1-4)

ASM., SPLIT GEAR (INCL. 1-4)
6

5137204 SHAFT, COMPENSATOR

SHAFT, COMPENSATOR
7

7556539 WASHER

WASHER
8

6230469 GEAR, COMPENSATOR, DRIVE

GEAR, COMPENSATOR, DRIVE
9

5135550 SLIDER, COMPENSATOR

SLIDER, COMPENSATOR
10

7042019 SPRING, BELLEVILLE, COMPENSATOR (BUILT 8/03/11 AND BEFORE)

SPRING, BELLEVILLE, COMPENSATOR (BUILT 8/03/11 AND BEFORE)
11

5137955 RETAINER, COMPENSATOR

RETAINER, COMPENSATOR
12

7556518 WASHER, FLAT (BUILT 8/03/11 AND BEFORE)

WASHER, FLAT (BUILT 8/03/11 AND BEFORE)
13

7556519 DISC, SPRING

DISC, SPRING
14

7547477 NUT

NUT
15

7518008 BOLT, OIL JET

BOLT, OIL JET
16

7555987 WASHER, FLAT

WASHER, FLAT
17

4012716 ROTOR, CHARGING

ROTOR, CHARGING
18

7721122 KEY, WOODRUFF

KEY, WOODRUFF
19

7710490 RING, RETAINING, 35 DEGREE

RING, RETAINING, 35 DEGREE
20

7556237 WASHER, FLAT

WASHER, FLAT
21

1015167 ASM., CRANKSHAFT GEAR STARTER DRIVE

ASM., CRANKSHAFT GEAR STARTER DRIVE
22

4060156 CLUTCH, STARTER DRIVE

CLUTCH, STARTER DRIVE
23

7517260 SCREW

SCREW
24

6230471 GEAR, CRANKSHAFT, PRIMARY, HCL

GEAR, CRANKSHAFT, PRIMARY, HCL
25

5137949 SPACER, COMPENSATOR (BUILT 8/04/11 AND AFTER)

SPACER, COMPENSATOR (BUILT 8/04/11 AND AFTER)
26

7043639 SPRING, BELLEVILLE, 2.54MM (BUILT 8/04/11 AND AFTER)

SPRING, BELLEVILLE, 2.54MM (BUILT 8/04/11 AND AFTER)
27

7556577 WASHER (BUILT 8/04/11 AND AFTER)

WASHER (BUILT 8/04/11 AND AFTER)
28

7043638 SPRING, BELLVILLE, .9MM (BUILT 8/04/11 AND AFTER)

SPRING, BELLVILLE, .9MM (BUILT 8/04/11 AND AFTER)
