WINDSHIELD для Polaris KINGPIN (CANADA) [V04CB16CA] - 2004 года выпуска

  • №
    Артикул
    Название
  • 1
    7518229 BOLT, CARRIAGE
    BOLT, CARRIAGE
  • 2
    7518411 BOLT, CARRIAGE
    BOLT, CARRIAGE
  • 3
    7079671 BADGE, WINDSHIELD STAMP
    BADGE, WINDSHIELD STAMP
  • 4
    5246994 BRACKET, WINDSHIELD, FRONT, TOP
    BRACKET, WINDSHIELD, FRONT, TOP
  • 5
    5812464 PAD, WINDSHIELD
    PAD, WINDSHIELD
  • 6
    5133932 SPACER, WINDSHIELD
    SPACER, WINDSHIELD
  • 7
    5434963 WINDSHIELD, MID
    WINDSHIELD, MID
  • 7
    5434741 WINDSHIELD, TALL
    WINDSHIELD, TALL
  • 8
    5246997 BRACKET, WINDSHIELD, REAR, TOP
    BRACKET, WINDSHIELD, REAR, TOP
  • 9
    7556323 WASHER ,FLAT
    WASHER ,FLAT
  • 10
    7547115 NUT, ACORN
    NUT, ACORN
  • 11
    2874679 KIT, WINDSHIELD CLAMP
    KIT, WINDSHIELD CLAMP
  • 12
    7517523 SCREW
    SCREW
  • 13
    7547184 NUT, ACORN
    NUT, ACORN
  • 14
    5246998 BRACKET, WINDSHIELD, REAR, LEFT HAND
    BRACKET, WINDSHIELD, REAR, LEFT HAND
  • 14
    5246999 BRACKET, WINDSHIELD, REAR, RIGHT HAND
    BRACKET, WINDSHIELD, REAR, RIGHT HAND
  • 15
    7556291 WASHER, FLAT
    WASHER, FLAT
  • 16
    7079506 DECAL, WARNING/CAUTION/CLEANING
    DECAL, WARNING/CAUTION/CLEANING
  • 17
    1014278 ASM., DEFLECTOR, LOWER, LEFT HAND
    ASM., DEFLECTOR, LOWER, LEFT HAND
  • 17
    1014279 ASM., DEFLECTOR, LOWER, RIGHT HAND
    ASM., DEFLECTOR, LOWER, RIGHT HAND
  • 18
    5246995 BRACKET, WINDSHIELD, FRONT, LEFT HAND
    BRACKET, WINDSHIELD, FRONT, LEFT HAND
  • 19
    5246996 BRACKET, WINDSHIELD, FRONT, RIGHT HAND
    BRACKET, WINDSHIELD, FRONT, RIGHT HAND
  • 19
    2874592 KIT, WINDSHIELD, LOW (INCL. ALL LESS 11,12,13,17)
    KIT, WINDSHIELD, LOW (INCL. ALL LESS 11,12,13,17)
  • 19
    2874589 KIT, WINDSHIELD, MED (INCL. ALL LESS 11,12,13,17)
    KIT, WINDSHIELD, MED (INCL. ALL LESS 11,12,13,17)
  • 19
    2874590 KIT, WINDSHIELD, TALL (INCL. ALL LESS 11,12,13,17)
    KIT, WINDSHIELD, TALL (INCL. ALL LESS 11,12,13,17)
