FRONT WHEEL (SPOKED) для Polaris VICTORY VEGAS (UK) [V03GB16UA] - 2003 года выпуска`
-
№АртикулНазвание
-
15133593 AXLE, FRONTAXLE, FRONT
-
27517517 SCREWSCREW
-
35334139 SPACER, BEARING, RIGHT HANDSPACER, BEARING, RIGHT HAND
-
45631481 SPACER, BEARING, LEFT HANDSPACER, BEARING, LEFT HAND
-
57517936 SCREWSCREW
-
63610094 SEALSEAL
-
73514405 BEARING, BALLBEARING, BALL
-
85334138 SPACER, BEARINGSPACER, BEARING
-
97710526 RING, RETAININGRING, RETAINING
-
107518071 SCREWSCREW
-
111910623 ROTOR, BRAKEROTOR, BRAKE
-
121520618 WEIGHT, BALANCEWEIGHT, BALANCE
-
131520366 ASM., WHEEL, FRONT (INCL. 6,7,8,9, RIM, WEIGHT, FLAP, AND SPOKES)ASM., WHEEL, FRONT (INCL. 6,7,8,9, RIM, WEIGHT, FLAP, AND SPOKES)
-
135133678 RIMRIM
-
135812234 FLAP, RIMFLAP, RIM
-
135334020 SPOKE, OUTERSPOKE, OUTER
-
135334022 SPOKE, INNERSPOKE, INNER
-
141821320 TUBE, TIRE, INNERTUBE, TIRE, INNER
-
155412263 TIRE, FRONTTIRE, FRONT
