MAIN FRAME для Polaris DELUXE TOURING CRUISER (49 STATE) [V02TD16DC] - 2002 года выпуска
-
№АртикулНазвание
-
17661027 PIN, KNURLEDPIN, KNURLED
-
27571637 WASHER, WAVEWASHER, WAVE
-
35242202 CAP, FORK LOCKCAP, FORK LOCK
-
47010085 LOCK, FRONT FORKLOCK, FRONT FORK
-
55411472 GROMMET, HEAD CASTINGGROMMET, HEAD CASTING
-
61013490-067 FRAME, MAINFRAME, MAIN
-
77710446 RING, RETAININGRING, RETAINING
-
83513506 BEARING, SPHERICALBEARING, SPHERICAL
-
97518057 SCREWSCREW
-
107518056 SCREWSCREW
-
117547039 NUTNUT
-
121013481-067 TUBE, FRAME, LOWER, LEFT HANDTUBE, FRAME, LOWER, LEFT HAND
-
131013482-067 TUBE, FRAME, LOWER, RIGHT HANDTUBE, FRAME, LOWER, RIGHT HAND
Все узлы модели:
- AIR BOX
- BATTERY BOX
- CAM AND VALVE COVERS
- CAMCHAIN AND TENSIONER
- CRANKCASE
- CRANKCASE BEARINGS
- CRANKSHAFT
- CYLINDER AND HEAD
- DECALS
- DRIVE CLUTCH
- ECM BOX
- ELECTRICAL
- ENGINE MOUNTING
- EXHAUST SYSTEM
- FLOOR BOARD AND SIDE STAND
- FRONT BRAKE
- FRONT DRIVE SPROCKET
- FRONT FENDER
- FRONT FORKS
- FRONT WHEEL
- FUEL SYSTEM
- HANDLEBAR
- HEADLIGHT
- HIGHWAY BAR
- IGNITION ASM
- LICENSE PLATE BRACKET
- • MAIN FRAME
- OIL COOLING
- OIL PUMP
- OIL PUMP MOUNTING
- OWNER'S MANUAL
- PRIMARY COVER
- PRIMARY DRIVE
- REAR BRAKE
- REAR SHOCK
- REAR WHEEL
- SADDLEBAGS
- SEAT
- SENSORS
- SHIFT FORKS/DRUM
- SHIFT LEVER
- STARTER MOTOR
- STRUT AND HANGER MOUNTING
- SUBFRAME
- SWING ARM
- TAILLIGHT
- TRANSMISSION
- TURN SIGNAL AND LIGHT BAR
- VALVE TRAIN
- WIND DEFLECTORS
- WINDSHIELD
