REAR RACK AND FENDERS для Polaris SPORTSMAN ACE 325 SAGE GREEN [A15DAA32AA] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    5450078-070 BOX, CARGO, REAR, BLACK
    BOX, CARGO, REAR, BLACK
  • 2
    5450076-498 FENDER, REAR, LEFT HAND, SAGEBRUSH GREEN (AA)
    FENDER, REAR, LEFT HAND, SAGEBRUSH GREEN (AA)
  • 3
    5450077-498 FENDER, REAR, RIGHT HAND, SAGEBRUSH GREEN (AA)
    FENDER, REAR, RIGHT HAND, SAGEBRUSH GREEN (AA)
  • 4
    5450079-070 PANEL, CLOSE OFF, BLACK
    PANEL, CLOSE OFF, BLACK
  • 5
    5450080-070 BOX, MAINT PANEL, REMOVABLE, BLACK
    BOX, MAINT PANEL, REMOVABLE, BLACK
  • 6
    5450299-070 PANEL, UNDERSEAT COVER, LEFT HAND, BLACK
    PANEL, UNDERSEAT COVER, LEFT HAND, BLACK
  • 7
    5450589-070 PANEL, UNDERSEAT COVER, RIGHT HAND, BLACK
    PANEL, UNDERSEAT COVER, RIGHT HAND, BLACK
  • 8
    5450392-070 GRILL, INTAKE COVER, LEFT HAND, BLACK
    GRILL, INTAKE COVER, LEFT HAND, BLACK
  • 9
    5450393-070 GRILL, INTAKE COVER, RIGHT HAND, BLACK
    GRILL, INTAKE COVER, RIGHT HAND, BLACK
  • 10
    5413428 GROMMET, LATCH
    GROMMET, LATCH
  • 11
    7081730 LATCH
    LATCH
  • 12
    7555919 WASHER
    WASHER
  • 13
    7519650 SCREW
    SCREW
  • 14
    7547674 NUT, U-TYPE
    NUT, U-TYPE
  • 15
    5412507 GROMMET
    GROMMET
  • 16
    5813858 FOIL, TANK, RES, SUMP
    FOIL, TANK, RES, SUMP
  • 17
    7661855 RIVET
    RIVET
