THROTTLE BODY MOUNTING для Polaris SPORTSMAN 800 EFI 6X6 - SAGE BRUSH GREEN METALLIC [A14CF76AA] - 2014 года выпуска
-
№АртикулНазвание
-
13021352 ASM., REED W/GASKET (INCL. 4-8)ASM., REED W/GASKET (INCL. 4-8)
-
21202836 ASM., THROTTLE BODY (INCL. THROTTLE POSITION SENSOR)ASM., THROTTLE BODY (INCL. THROTTLE POSITION SENSOR)
-
35412836 SEAL, VALVE COVERSEAL, VALVE COVER
-
95438320 COVER, CASE, BREATHERCOVER, CASE, BREATHER
-
107516822 SCREWSCREW
-
113021671 PLUG, SPARK, CHAMPION RC7YC3PLUG, SPARK, CHAMPION RC7YC3
-
121240494 ADAPTER, THROTTLE BODYADAPTER, THROTTLE BODY
-
137516734 SCREWSCREW
-
147081623 CLAMP, HOSECLAMP, HOSE
-
157516822 SCREWSCREW
-
165138505 COVER, VALVECOVER, VALVE
-
175813659 GASKET, BREATHER, COVERGASKET, BREATHER, COVER
