MAIN GEARCASE для Polaris RZR 4 XP JAGGED X [R13XT9EAL] - 2013 года выпуска

  • №
    Артикул
    Название
  • 1
    1333162 ASM-GEARCASE,COMPLETE (INCL. ALL)
    ASM-GEARCASE,COMPLETE (INCL. ALL)
  • 2
    3234756 PLUG, MAGNETIC
    PLUG, MAGNETIC
  • 3
    3234898 SCREW, HEX FLANGE HEAD
    SCREW, HEX FLANGE HEAD
  • 4
    3235206 SCREW, HEX FLANGE HEAD
    SCREW, HEX FLANGE HEAD
  • 5
    3235207 SCREW, HEX FLANGE
    SCREW, HEX FLANGE
  • 6
    3235208 SCREW, SOCKET HEAD, CAP
    SCREW, SOCKET HEAD, CAP
  • 7
    3235332 SCREW, SOCKET HEAD, CAP
    SCREW, SOCKET HEAD, CAP
  • 8
    3235210 NUT, LOCK HEX FLANGE
    NUT, LOCK HEX FLANGE
  • 9
    3234091 WASHER, CUP
    WASHER, CUP
  • 10
    3235211 WASHER
    WASHER
  • 11
    3235212 WASHER
    WASHER
  • 12
    3235213 WASHER
    WASHER
  • 13
    3234330 PIN, DOWEL
    PIN, DOWEL
  • 14
    7043746 PIN, SPRING, SLOTTED
    PIN, SPRING, SLOTTED
  • 15
    3233106 RING, RETAINING BASIC, EXTERNAL
    RING, RETAINING BASIC, EXTERNAL
  • 16
    3233834 RING, SNAP
    RING, SNAP
  • 17
    3233364 RING, RETAINING, SHAFT
    RING, RETAINING, SHAFT
  • 18
    3234318 RING, RETAINING, EXTERNAL
    RING, RETAINING, EXTERNAL
  • 19
    3234269 RING, RETAINING BASIC, INTERNAL
    RING, RETAINING BASIC, INTERNAL
  • 20
    3234090 RING, RETAINING BASIC, EXTERNAL
    RING, RETAINING BASIC, EXTERNAL
  • 21
    3234205 RING, RETAINING
    RING, RETAINING
  • 22
    3235214 RING, RETAINING BASIC, EXTERNAL
    RING, RETAINING BASIC, EXTERNAL
  • 23
    3235216 RING, RETAINING
    RING, RETAINING
  • 24
    3233378 WASHER, THRUST
    WASHER, THRUST
  • 25
    3234642 WASHER, THRUST
    WASHER, THRUST
  • 26
    3234272 SHIM
    SHIM
  • 27
    3234273 SHIM
    SHIM
  • 28
    3233014 BEARING, NEEDLE, CAGE ASM.
    BEARING, NEEDLE, CAGE ASM.
  • 29
    3233019 BEARING, BALL
    BEARING, BALL
  • 30
    3233020 BEARING, BALL
    BEARING, BALL
  • 31
    3233268 BEARING, BALL
    BEARING, BALL
  • 32
    3234065 BEARING, BALL
    BEARING, BALL
  • 33
    3233384 BEARING, NEEDLE, CAGE ASM.
    BEARING, NEEDLE, CAGE ASM.
  • 34
    3235218 BEARING, BALL
    BEARING, BALL
  • 35
    3234652 BEARING, BALL
    BEARING, BALL
  • 36
    3234078 SPRING, COMPRESSION
    SPRING, COMPRESSION
  • 37
    3234089 SPRING, COMPRESSION
    SPRING, COMPRESSION
  • 38
    3233820 SPRING, COMPRESSION, DETENT
    SPRING, COMPRESSION, DETENT
  • 39
    3234278 TUBE, SNORKEL
    TUBE, SNORKEL
  • 40
    3234188 COVER, SECTOR GEARS
    COVER, SECTOR GEARS
  • 41
    3235444 SUBASM., RIGHT HAND CASE (INCL. ALL HARDWARE)
    SUBASM., RIGHT HAND CASE (INCL. ALL HARDWARE)
  • 42
    3235491 SUBASM., LEFT HAND CASE (INCL. ALL HARDWARE)
    SUBASM., LEFT HAND CASE (INCL. ALL HARDWARE)
  • 43
    3235463 DRUM, SHIFT MACH
    DRUM, SHIFT MACH
  • 44
    3233839 GEAR, SECTOR 16T
    GEAR, SECTOR 16T
  • 45
    3233832 GEAR, SECTOR, 31T
    GEAR, SECTOR, 31T
  • 46
    3235452 PAWL, DETENT
    PAWL, DETENT
  • 47
    3235453 STAR, DETENT
    STAR, DETENT
  • 48
    3235456 PLATE, PARK, 12-FACE
    PLATE, PARK, 12-FACE
  • 49
    3235335 SUBASM., 53T GEAR (INCL. BEARINGS)
    SUBASM., 53T GEAR (INCL. BEARINGS)
  • 50
    3235223 SHAFT, IDLER 29T
    SHAFT, IDLER 29T
  • 51
    3235224 SHAFT, REVERSE 29T
    SHAFT, REVERSE 29T
  • 52
    3235225 SHAFT, FRONT OUTPUT
    SHAFT, FRONT OUTPUT
  • 53
    3235492 SHAFT, INPUT 42T/20T/25T
    SHAFT, INPUT 42T/20T/25T
  • 54
    3235227 BELLCRANK, 92 DEGREE
    BELLCRANK, 92 DEGREE
  • 55
    3234073 COLLAR, SHIFT
    COLLAR, SHIFT
  • 56
    3234079 RAIL, SHIFT SHAFT
    RAIL, SHIFT SHAFT
  • 57
    3234230 TUBE, VENT
    TUBE, VENT
  • 58
    3235457 SHIFT DOG, PARK
    SHIFT DOG, PARK
  • 59
    3235229 GEAR, 44T STAGE 2
    GEAR, 44T STAGE 2
  • 60
    3235454 FORK, SHIFT
    FORK, SHIFT
  • 61
    3235231 SPROCKET 48T, 6-FACE
    SPROCKET 48T, 6-FACE
  • 62
    3235232 GEAR, LOW 67T
    GEAR, LOW 67T
  • 63
    3235233 ENGAGEMENT DOG, 6-FACE
    ENGAGEMENT DOG, 6-FACE
  • 64
    3235234 GEAR, 53T
    GEAR, 53T
  • 65
    3235336 SUBASM.,SHAFT, INCL. BEARING AND RET. RING
    SUBASM.,SHAFT, INCL. BEARING AND RET. RING
  • 66
    3235236 GEAR, 46T STAGE 3
    GEAR, 46T STAGE 3
  • 67
    3235237 GEAR, 13T SNORKEL
    GEAR, 13T SNORKEL
  • 68
    3235238 SHAFT, SHIFT
    SHAFT, SHIFT
  • 69
    3235239 WELDMENT, REAR MOUNT BRACKET
    WELDMENT, REAR MOUNT BRACKET
  • 70
    3235351 BRACKET, REAR MOUNT
    BRACKET, REAR MOUNT
  • 71
    3235241 COVER, BEARING, CENTER DRIVE
    COVER, BEARING, CENTER DRIVE
  • 72
    3235243 SPACER
    SPACER
  • 73
    3234737 CHAIN, SILENT
    CHAIN, SILENT
  • 74
    7661999 SWITCH, ROTARY , 2 PIN RESISTIVE
    SWITCH, ROTARY , 2 PIN RESISTIVE
  • 75
    3233076 O-RING
    O-RING
  • 76
    3234302 O-RING
    O-RING
  • 77
    3233869 O-RING
    O-RING
  • 78
    3234113 SEAL, TRIPLE LIP
    SEAL, TRIPLE LIP
  • 79
    3235495 SEAL, TRIPLE LIP
    SEAL, TRIPLE LIP
  • 80
    3235052 SEAL, TRIPLE LIP
    SEAL, TRIPLE LIP
  • 81
    4012167 SENSOR, SPEED
    SENSOR, SPEED
  • 82
    3235496 BEARING
    BEARING
  • 83
    3235327 SPRING, WAVE
    SPRING, WAVE
  • 84
    3235350 BRACKET, WIRE HARNESS
    BRACKET, WIRE HARNESS
  • 85
    3234755 PLUG
    PLUG
  • 1
    1333162 ASM-GEARCASE,COMPLETE (INCL. ALL)
    ASM-GEARCASE,COMPLETE (INCL. ALL)
  • 2
    3234756 PLUG, MAGNETIC
    PLUG, MAGNETIC
  • 3
    3234898 SCREW, HEX FLANGE HEAD
    SCREW, HEX FLANGE HEAD
  • 4
    3235206 SCREW, HEX FLANGE HEAD
    SCREW, HEX FLANGE HEAD
  • 5
    3235207 SCREW, HEX FLANGE
    SCREW, HEX FLANGE
  • 6
    3235208 SCREW, SOCKET HEAD, CAP
    SCREW, SOCKET HEAD, CAP
  • 7
    3235332 SCREW, SOCKET HEAD, CAP
    SCREW, SOCKET HEAD, CAP
  • 8
    3235210 NUT, LOCK HEX FLANGE
    NUT, LOCK HEX FLANGE
  • 9
    3234091 WASHER, CUP
    WASHER, CUP
  • 10
    3235211 WASHER
    WASHER
  • 11
    3235212 WASHER
    WASHER
  • 12
    3235213 WASHER
    WASHER
  • 13
    3234330 PIN, DOWEL
    PIN, DOWEL
  • 14
    7043746 PIN, SPRING, SLOTTED
    PIN, SPRING, SLOTTED
  • 15
    3233106 RING, RETAINING BASIC, EXTERNAL
    RING, RETAINING BASIC, EXTERNAL
  • 16
    3233834 RING, SNAP
    RING, SNAP
  • 17
    3233364 RING, RETAINING, SHAFT
    RING, RETAINING, SHAFT
  • 18
    3234318 RING, RETAINING, EXTERNAL
    RING, RETAINING, EXTERNAL
  • 19
    3234269 RING, RETAINING BASIC, INTERNAL
    RING, RETAINING BASIC, INTERNAL
  • 20
    3234090 RING, RETAINING BASIC, EXTERNAL
    RING, RETAINING BASIC, EXTERNAL
  • 21
    3234205 RING, RETAINING
    RING, RETAINING
  • 22
    3235214 RING, RETAINING BASIC, EXTERNAL
    RING, RETAINING BASIC, EXTERNAL
  • 23
    3235216 RING, RETAINING
    RING, RETAINING
  • 24
    3233378 WASHER, THRUST
    WASHER, THRUST
  • 25
    3234642 WASHER, THRUST
    WASHER, THRUST
  • 26
    3234272 SHIM
    SHIM
  • 27
    3234273 SHIM
    SHIM
  • 28
    3233014 BEARING, NEEDLE, CAGE ASM.
    BEARING, NEEDLE, CAGE ASM.
  • 29
    3233019 BEARING, BALL
    BEARING, BALL
  • 30
    3233020 BEARING, BALL
    BEARING, BALL
  • 31
    3233268 BEARING, BALL
    BEARING, BALL
  • 32
    3234065 BEARING, BALL
    BEARING, BALL
  • 33
    3233384 BEARING, NEEDLE, CAGE ASM.
    BEARING, NEEDLE, CAGE ASM.
  • 34
    3235218 BEARING, BALL
    BEARING, BALL
  • 35
    3234652 BEARING, BALL
    BEARING, BALL
  • 36
    3234078 SPRING, COMPRESSION
    SPRING, COMPRESSION
  • 37
    3234089 SPRING, COMPRESSION
    SPRING, COMPRESSION
  • 38
    3233820 SPRING, COMPRESSION, DETENT
    SPRING, COMPRESSION, DETENT
  • 39
    3234278 TUBE, SNORKEL
    TUBE, SNORKEL
  • 40
    3234188 COVER, SECTOR GEARS
    COVER, SECTOR GEARS
  • 41
    3235444 SUBASM., RIGHT HAND CASE (INCL. ALL HARDWARE)
    SUBASM., RIGHT HAND CASE (INCL. ALL HARDWARE)
  • 42
    3235491 SUBASM., LEFT HAND CASE (INCL. ALL HARDWARE)
    SUBASM., LEFT HAND CASE (INCL. ALL HARDWARE)
  • 43
    3235463 DRUM, SHIFT MACH
    DRUM, SHIFT MACH
  • 44
    3233839 GEAR, SECTOR 16T
    GEAR, SECTOR 16T
  • 45
    3233832 GEAR, SECTOR, 31T
    GEAR, SECTOR, 31T
  • 46
    3235452 PAWL, DETENT
    PAWL, DETENT
  • 47
    3235453 STAR, DETENT
    STAR, DETENT
  • 48
    3235456 PLATE, PARK, 12-FACE
    PLATE, PARK, 12-FACE
  • 49
    3235335 SUBASM., 53T GEAR (INCL. BEARINGS)
    SUBASM., 53T GEAR (INCL. BEARINGS)
  • 50
    3235223 SHAFT, IDLER 29T
    SHAFT, IDLER 29T
  • 51
    3235224 SHAFT, REVERSE 29T
    SHAFT, REVERSE 29T
  • 52
    3235225 SHAFT, FRONT OUTPUT
    SHAFT, FRONT OUTPUT
  • 53
    3235492 SHAFT, INPUT 42T/20T/25T
    SHAFT, INPUT 42T/20T/25T
  • 54
    3235227 BELLCRANK, 92 DEGREE
    BELLCRANK, 92 DEGREE
  • 55
    3234073 COLLAR, SHIFT
    COLLAR, SHIFT
  • 56
    3234079 RAIL, SHIFT SHAFT
    RAIL, SHIFT SHAFT
  • 57
    3234230 TUBE, VENT
    TUBE, VENT
  • 58
    3235457 SHIFT DOG, PARK
    SHIFT DOG, PARK
  • 59
    3235229 GEAR, 44T STAGE 2
    GEAR, 44T STAGE 2
  • 60
    3235454 FORK, SHIFT
    FORK, SHIFT
  • 61
    3235231 SPROCKET 48T, 6-FACE
    SPROCKET 48T, 6-FACE
  • 62
    3235232 GEAR, LOW 67T
    GEAR, LOW 67T
  • 63
    3235233 ENGAGEMENT DOG, 6-FACE
    ENGAGEMENT DOG, 6-FACE
  • 64
    3235234 GEAR, 53T
    GEAR, 53T
  • 65
    3235336 SUBASM.,SHAFT, INCL. BEARING AND RET. RING
    SUBASM.,SHAFT, INCL. BEARING AND RET. RING
  • 66
    3235236 GEAR, 46T STAGE 3
    GEAR, 46T STAGE 3
  • 67
    3235237 GEAR, 13T SNORKEL
    GEAR, 13T SNORKEL
  • 68
    3235238 SHAFT, SHIFT
    SHAFT, SHIFT
  • 69
    3235239 WELDMENT, REAR MOUNT BRACKET
    WELDMENT, REAR MOUNT BRACKET
  • 70
    3235351 BRACKET, REAR MOUNT
    BRACKET, REAR MOUNT
  • 71
    3235241 COVER, BEARING, CENTER DRIVE
    COVER, BEARING, CENTER DRIVE
  • 72
    3235243 SPACER
    SPACER
  • 73
    3234737 CHAIN, SILENT
    CHAIN, SILENT
  • 74
    7661999 SWITCH, ROTARY , 2 PIN RESISTIVE
    SWITCH, ROTARY , 2 PIN RESISTIVE
  • 75
    3233076 O-RING
    O-RING
  • 76
    3234302 O-RING
    O-RING
  • 77
    3233869 O-RING
    O-RING
  • 78
    3234113 SEAL, TRIPLE LIP
    SEAL, TRIPLE LIP
  • 79
    3235495 SEAL, TRIPLE LIP
    SEAL, TRIPLE LIP
  • 80
    3235052 SEAL, TRIPLE LIP
    SEAL, TRIPLE LIP
  • 81
    4012167 SENSOR, SPEED
    SENSOR, SPEED
  • 82
    3235496 BEARING
    BEARING
  • 83
    3235327 SPRING, WAVE
    SPRING, WAVE
  • 84
    3235350 BRACKET, WIRE HARNESS
    BRACKET, WIRE HARNESS
  • 85
    3234755 PLUG
    PLUG
