AIR INTAKE SYSTEM для Polaris OUTLAW 90 - (BRIGHT WHITE) [A12KA09AD] - 2012 года выпуска
-
№АртикулНазвание
-
10450824 BOLT W/WASHERBOLT W/WASHER
-
20453331 DUCT, INLETDUCT, INLET
-
30453655 CLAMPCLAMP
-
40453656 BOOT, DUCTBOOT, DUCT
-
50453187 CLIPCLIP
-
60450880 NUTNUT
-
70453184 SEPARATOR, OILSEPARATOR, OIL
-
80450865 CLIPCLIP
-
90454006 TUBE, OILTUBE, OIL
-
100453516 CLIPCLIP
-
110454007 TUBE, OILTUBE, OIL
-
120452215 BOLTBOLT
-
130454008 TUBE, BREATHER, VENTILATEDTUBE, BREATHER, VENTILATED
-
140452795 CLIPCLIP
-
150453658 CLAMPCLAMP
-
160453659 BOOTBOOT
-
170453725 HOSE, DRAINHOSE, DRAIN
-
180453661 CLIPCLIP
-
190453518 BOLTBOLT
-
200453666 BRACKET, MOUNT, AIR BOXBRACKET, MOUNT, AIR BOX
-
210453660 CLIPCLIP
-
220453662 BOX, AIR CLEANERBOX, AIR CLEANER
-
230452215 BOLTBOLT
-
240453663 FILTER, AIR CLEANERFILTER, AIR CLEANER
-
250454620 FOAM, INTAKE, AIR CLEANERFOAM, INTAKE, AIR CLEANER
-
260453484 GASKETGASKET
-
270453332 DUCT, OUTLETDUCT, OUTLET
-
280453665 COVER, AIR CLEANERCOVER, AIR CLEANER
