GEARCASE - REAR - INTERNAL COMPONENTS (BUILT 12/02/08 AND AFTER) для Polaris SPORTSMAN XP 850 INTL (A09ZN8CFL) (SUNSET RED) - 2009 года выпуска`
-
№АртикулНазвание
-
11332752 GEARCASE, REAR (INCL. ALL)GEARCASE, REAR (INCL. ALL)
-
23234756 PLUG, SOCKET HEAD W/MAGNETPLUG, SOCKET HEAD W/MAGNET
-
33234898 SCREWSCREW
-
43234776 NUT, HEXNUT, HEX
-
53234777 WASHER, LOCKINGWASHER, LOCKING
-
63234330 PIN, DOWELPIN, DOWEL
-
73234158 RING, RETAININGRING, RETAINING
-
83233581 SHIMSHIM
-
93234799 BEARING, NEEDLEBEARING, NEEDLE
-
103233714 BEARING, BALLBEARING, BALL
-
113233268 BEARING, BALLBEARING, BALL
-
123234791 CASE, MAINCASE, MAIN
-
133234796 KIT, CASE, LEFT HAND (INCL. 6)KIT, CASE, LEFT HAND (INCL. 6)
-
143234798 SHAFT, PINION, 10TSHAFT, PINION, 10T
-
153234792 GEAR, 37TGEAR, 37T
-
163234230 TUBE, VENTTUBE, VENT
-
173234782 COUPLERCOUPLER
-
183234755 PLUG, SOCKET HEADPLUG, SOCKET HEAD
-
193234793 SEAL, TRIPLE LIPSEAL, TRIPLE LIP
-
203234794 SEAL, TRIPLE LIPSEAL, TRIPLE LIP
-
213234785 O-RINGO-RING
