GEARCASE для Polaris SPORTSMAN 300 4X4 (A09LH27AX) (GREEN/BLACK) - 2009 года выпуска

  • №
    Артикул
    Название
  • -
    1332699 ASM-TRANSMISSION,SHAFT,4X4,300
    ASM-TRANSMISSION,SHAFT,4X4,300
  • 1
    3233834 RING-RETAINING
    RING-RETAINING
  • 2
    3233835 SWITCH-ROTARY,6 PIN
    SWITCH-ROTARY,6 PIN
  • 3
    3234329 SCREW,HEXFLANGEHEAD,M8X1.25X30
    SCREW,HEXFLANGEHEAD,M8X1.25X30
  • 4
    3234587 BELL CRANK
    BELL CRANK
  • 5
    3234450 245611: CASE, RIGHT HAND MACH
    245611: CASE, RIGHT HAND MACH
  • 6
    3234244 PIN DOWEL 5/16 X 1.0
    PIN DOWEL 5/16 X 1.0
  • 7
    3234611 CASE
    CASE
  • 8
    3234302 O-RING, -113
    O-RING, -113
  • 9
    4012167 SENSOR-SPEED,TRANS
    SENSOR-SPEED,TRANS
  • 10
    3234311 SCREW, HEX HEAD, M6 X 1 X 16
    SCREW, HEX HEAD, M6 X 1 X 16
  • 11
    3234333 PLUG,M12X1.5 HEXHEAD,W/O-RING
    PLUG,M12X1.5 HEXHEAD,W/O-RING
  • 12
    3234330 PIN, DOWEL, 6 X 20
    PIN, DOWEL, 6 X 20
  • 13
    3234315 SEAL, 35 X 62 X 8
    SEAL, 35 X 62 X 8
  • 14
    3234312 RING,RETNING BVLD INTRNL 2.440
    RING,RETNING BVLD INTRNL 2.440
  • 15
    3234310 RING,RETNNG BEVELED EXTNL1.375
    RING,RETNNG BEVELED EXTNL1.375
  • 16
    3233265 BEARING, BALL
    BEARING, BALL
  • 17
    3234630 ASM., SHAFT, 11T
    ASM., SHAFT, 11T
  • 18
    3234313 BEARING, PLAIN.500X.594X.625
    BEARING, PLAIN.500X.594X.625
  • 19
    3234230 TUBE-VENT,90-1/4'' HOSE
    TUBE-VENT,90-1/4'' HOSE
  • 20
    3234316 NUT,LOCKHEXFLANGE,NYLON M14X2
    NUT,LOCKHEXFLANGE,NYLON M14X2
  • 21
    3234610 PLUG-DRAIN,W/ MAGNET
    PLUG-DRAIN,W/ MAGNET
