SUSPENSION - FRONT STRUT для Polaris SPORTSMAN 700 EFI (A05MH68AS) (INDY RED) - 2005 года выпуска

  • №
    Артикул
    Название
  • 1
    7547104 NUT
    NUT
  • 2
    7555749 WASHER
    WASHER
  • 3
    5810291 SPACER, RUBBER
    SPACER, RUBBER
  • 4
    5432872 PIVOT, BALL, TOP
    PIVOT, BALL, TOP
  • 5
    5132062 SPACER (1/2 20)
    SPACER (1/2 20)
  • 6
    5432871 PIVOT, BALL (BOTTOM)
    PIVOT, BALL (BOTTOM)
  • 7
    5243364 RETAINER SPRING
    RETAINER SPRING
  • 8
    7042301-293 SPRING, COMP (75 111#/IN, 13. 5, RD)
    SPRING, COMP (75 111#/IN, 13. 5, RD)
  • 9
    5412665 BUMPER, MCU (17. 8MM ID)
    BUMPER, MCU (17. 8MM ID)
  • 10
    7515339 BOLT
    BOLT
  • 11
    7558402 WASHER, FLAT
    WASHER, FLAT
  • 12
    5134154 HUBSTRUT, VL ASSY. (LEFT)
    HUBSTRUT, VL ASSY. (LEFT)
  • 12
    5134155 HUBSTRUT, VL ASSY. (RIGHT)
    HUBSTRUT, VL ASSY. (RIGHT)
  • 13
    7710507 RING, RETAINING 2.500 INTERNAL
    RING, RETAINING 2.500 INTERNAL
  • 14
    3514342 BEARING AXLE TUBE/HUBSTRUT
    BEARING AXLE TUBE/HUBSTRUT
  • 15
    7080306 FITTING, LUBE. W/BALL CHECK
    FITTING, LUBE. W/BALL CHECK
  • 16
    7542324 NUT, NYLOK
    NUT, NYLOK
  • 18
    7552901 WASHER, SPRING LOCK
    WASHER, SPRING LOCK
  • 19
    7512365 SCREW, CAP
    SCREW, CAP
  • 20
    7080367 CLAMP, CABLE
    CLAMP, CABLE
  • 21
    5211115 WASHER
    WASHER
  • 22
    7041762 STRUT (FRONT)
    STRUT (FRONT)
