STEERING POST для Polaris SPORTSMAN 90 (A03FA09CC) (CAMO GREEN METALLIC ) - 2003 года выпуска

  • №
    Артикул
    Название
  • 1
    0450505 HOLDER, STEERING SHAFT
    HOLDER, STEERING SHAFT
  • 2
    0450915 SHAFT, STEERING
    SHAFT, STEERING
  • 3
    0450918 TIE ROD ASSY. (LEFT)
    TIE ROD ASSY. (LEFT)
  • 4
    0450395 PIN, COTTER
    PIN, COTTER
  • 5
    0450502 NUT, LOCK
    NUT, LOCK
  • 6
    0450507 PIN, COTTER
    PIN, COTTER
  • 7
    0450916 KNUCKLE (LEFT)
    KNUCKLE (LEFT)
  • 8
    0450276 NUT, LOCK
    NUT, LOCK
  • 9
    0450719 PIN, COTTER
    PIN, COTTER
  • 10
    0450491 SEAL, OIL
    SEAL, OIL
  • 11
    0450161 CIRCLIP, INTERNAL
    CIRCLIP, INTERNAL
  • 12
    0450493 BEARING, BALL
    BEARING, BALL
  • 13
    0450389 SEAL, OIL
    SEAL, OIL
  • 14
    0450390 SPACER (INNER)
    SPACER (INNER)
  • 15
    0450878 NUT, LOCK, NYLON
    NUT, LOCK, NYLON
  • 16
    0450917 KNUCKLE (RIGHT)
    KNUCKLE (RIGHT)
  • 17
    0450919 TIE ROD ASSY. (RIGHT)
    TIE ROD ASSY. (RIGHT)
  • 18
    0450268 NUT, FLANGE
    NUT, FLANGE
  • 19
    0450499 SLEEVE, STEERING SHAFT
    SLEEVE, STEERING SHAFT
