FENDER - FRONT W/ SIDE PANELS для Polaris MAGNUM 500 (A02CD50AA) - 2002 года выпуска`
-
№АртикулНазвание
-
15811491 FOIL,RH,SIDEPANEL,GEN IVFOIL,RH,SIDEPANEL,GEN IV
-
25812386 FOIL-SIDE PANEL,RHFOIL-SIDE PANEL,RH
-
32632284-317 PANEL/FOAM,LH,GUN METALPANEL/FOAM,LH,GUN METAL
-
32631977-317 PANEL/FOIL,RH,GUNMETALPANEL/FOIL,RH,GUNMETAL
-
47512232 BOLTBOLT
-
55432088-317 COVER-FRONT,GUNMETALCOVER-FRONT,GUNMETAL
-
67670085 CLIP,SPRINGCLIP,SPRING
-
72632299-317 CAB,FRONT,SVC,GUN METALCAB,FRONT,SVC,GUN METAL
-
87670057 NUT, SPEEDNUT, SPEED
-
97670135 NUT-SPEED,3/16NUT-SPEED,3/16
-
107661645 RIVETRIVET
-
117517312 SCREWSCREW
-
125431798-070 GUARD-MUD,FRONT,LH,BLKGUARD-MUD,FRONT,LH,BLK
-
125431799-070 GUARD-MUD,FRONT,RH,BLKGUARD-MUD,FRONT,RH,BLK
-
137541925 NUTNUT
-
147555792 WASHERWASHER
-
157512085 SCREWSCREW
-
164020139 CLIP, PLASTICCLIP, PLASTIC
-
178450073-600 LINE,BREATHER,3/8 ID.LINE,BREATHER,3/8 ID.
-
187555931 WASHERWASHER
-
197542122 NUT-LOCKNUT-LOCK
-
207621509 RIVET,PLASTI-LOC.RIVET,PLASTI-LOC.
-
215811917 SHIELD-DEFLECTORSHIELD-DEFLECTOR
Все узлы модели:
- AIR BOX ASSY.
- BRAKE - FRONT
- BRAKE - MASTER CYLINDER W/ BRAKE LINE
- BRAKE - REAR
- CAMSHAFT W/ VALVE ASSY.
- CARBURETOR
- CLUTCH - DRIVE
- CLUTCH - DRIVEN
- CLUTCH COVER
- COOLING SYSTEM
- CRANKCASE
- CRANKSHAFT W/ PISTON
- CYLINDER
- DECALS
- DIFFERENTIAL - FRONT
- DIFFERENTIAL - REAR
- DRIVESHAFT - FRONT
- DRIVESHAFT - FRONT INTERMEDIATE
- ELECTRICAL W/ TAILLIGHT ASSY.
- EXHAUST SYSTEM
- • FENDER - FRONT W/ SIDE PANELS
- FENDER - REAR W/ SEAT - FRAME
- FUEL PUMP
- FUEL TANK AND CARBURETOR MOUNTING
- GEAR SELECTOR
- GEARCASE
- GEARCASE SELECTOR MOUNTING
- HANDLEBAR - THROTTLE ASSY. W/ CABLE
- HANDLEBAR W/ HEADLIGHT
- MAGNETO
- MOUNTING - ENGINE
- MOUNTING - TRANSMISSION
- OIL FILTER
- OIL PUMP
- OIL TANK (IF BUILT AFTER 1/02/02)
- OIL TANK (IF BUILT BEFORE 1/02/02)
- RACK AND BUMPER MOUNTING - FRONT
- RACK AND BUMPER MOUNTING - REAR
- SHOCK ABSORBER
- STARTER - RECOIL
- STARTING MOTOR
- STEERING POST
- SUSPENSION - FRONT A - ARM W/ TIE RODS
- SUSPENSION - FRONT STRUT
- SUSPENSION - REAR SWING ARM W/ AXLE - SHAFT
- TOOL KIT
- WATER PUMP
- WHEEL - FRONT
- WHEEL - REAR
