SUSPENSION - REAR SWING ARM W/ AXLE для Polaris MAGNUM 325 4X4 HDS (A01CD32FB) (GUN METAL) - 2001 года выпуска

  • №
    Артикул
    Название
  • 1
    5412022 O-RING
    O-RING
  • 2
    5131935 HUB, WHEEL (4WD)
    HUB, WHEEL (4WD)
  • 3
    7515523 STUD
    STUD
  • 4
    5244882 DISC, BRAKE (REAR, 8.125X.188)
    DISC, BRAKE (REAR, 8.125X.188)
  • 6
    7517481 SCREW, SS
    SCREW, SS
  • 7
    7517604 BOLT
    BOLT
  • 8
    7555721 WASHER
    WASHER
  • 9
    7542703 NUT, FLEX
    NUT, FLEX
  • 10
    5411532 CAP, SWINGARM PIVOT
    CAP, SWINGARM PIVOT
  • 11
    5131863 NUT, JAM SWINGARM PIVOT
    NUT, JAM SWINGARM PIVOT
  • 12
    5131864 PIVOT, SWINGARM THREADED
    PIVOT, SWINGARM THREADED
  • 13
    3610072 SEAL, SWINGARM PIVOT
    SEAL, SWINGARM PIVOT
  • 14
    3554506 BEARING, TAPER ROLL.CONE
    BEARING, TAPER ROLL.CONE
  • 15
    3554507 BEARING, TAPER ROLL CUP
    BEARING, TAPER ROLL CUP
  • 16
    5411602 SEAL, SWINGARM PIVOT
    SEAL, SWINGARM PIVOT
  • 17
    1541577 SWINGARM, ASSY. (INCL. 15,16)
    SWINGARM, ASSY. (INCL. 15,16)
  • 18
    5132201 COUPLING, PROP SHAFT GREASED
    COUPLING, PROP SHAFT GREASED
  • 18
    7080433 ZERK, FITTING THREADED
    ZERK, FITTING THREADED
  • 19
    5411092 O-RING
    O-RING
  • 20
    1380137 PROPSHAFT ASSY. (REAR)
    PROPSHAFT ASSY. (REAR)
  • 21
    5132683 PIVOT, SWINGARM (RIGHT)
    PIVOT, SWINGARM (RIGHT)
  • 22
    7553201 LOCK WASHER
    LOCK WASHER
  • 23
    7517585 BOLT, HEX HEAD GR5-Z
    BOLT, HEX HEAD GR5-Z
  • 24
    5132699 AXLE (REAR)
    AXLE (REAR)
  • 25
    7517612 SCREW
    SCREW
  • 26
    5411531 O-RING
    O-RING
  • 28
    1012881 SKID PLATE (REAR)
    SKID PLATE (REAR)
  • 28
    5242851-067 PLATE, SKID HOUSING (REAR/BLACK)
    PLATE, SKID HOUSING (REAR/BLACK)
  • 28
    5811716 PAD, RUBBER
    PAD, RUBBER
  • 29
    5132698 COLLAR, AXLE LOCK
    COLLAR, AXLE LOCK
  • 30
    5411707 O-RING
    O-RING
  • 31
    7078261 DECAL, HITCH (1225)
    DECAL, HITCH (1225)
  • 32
    7661913 PIN, SPRING
    PIN, SPRING
  • 33
    5245050 CLAMP, BRAKE LINE (REAR)
    CLAMP, BRAKE LINE (REAR)
  • 34
    7512017 SCREW
    SCREW
  • 35
    1013264 CRADLE, SHAFT
    CRADLE, SHAFT
  • 36
    3514342 BEARING, HUBSTRUT VISCO
    BEARING, HUBSTRUT VISCO
  • 37
    7710507 RING, RET. (2.500 INT'L)
    RING, RET. (2.500 INT'L)
  • 38
    7512325 BOLT
    BOLT
