FLYWHEEL, STATOR AND STARTER MOTOR для Mercury - 40 (4 CYL.) 0C159200 AND UP

  • №
    Артикул
    Название
  • 1
    893943A01 SHOCK ROD ASSEMBLY KIT
    SHOCK ROD ASSEMBLY KIT
  • 2
    813428 CYLINDER END CAP
    CYLINDER END CAP
  • 3
    813429 SHOCK PISTON ASSEMBLY
    SHOCK PISTON ASSEMBLY
  • 4
    813432A3 CYLINDER REBUILD KIT
    CYLINDER REBUILD KIT
  • 5
    893903A01 MEMORY PISTON KIT (SEE FOOTNOTE & ILLUSTRATION)
    SUPERSEDES TO ANOTHER PART NUMBER
    MEMORY PISTON KIT (SEE FOOTNOTE & ILLUSTRATION)
    SUPERSEDES TO ANOTHER PART NUMBER
  • 5
    810776 MEMORY PISTON KIT (SEE FOOTNOTE & ILLUSTRATION)
    MEMORY PISTON KIT (SEE FOOTNOTE & ILLUSTRATION)
  • 6
    810777 CYLINDER KIT
    DESIGN I SEE ILLUSTRATION
    CYLINDER KIT
    DESIGN I SEE ILLUSTRATION
  • 7
    893919A01 SCREW AND SEAL KIT
    DESIGN I SEE ILLUSTRATION
    SCREW AND SEAL KIT
    DESIGN I SEE ILLUSTRATION
  • 8
    811227 PUMP
    DESIGN I SEE ILLUSTRATION
    PUMP
    DESIGN I SEE ILLUSTRATION
  • 9
    813441 MANIFOLD ASSEMBLY
    DESIGN I SEE ILLUSTRATION
    MANIFOLD ASSEMBLY
    DESIGN I SEE ILLUSTRATION
  • 6
    8M0055016 CYLINDER KIT
    DESIGN II SEE ILLUSTRATION
    CYLINDER KIT
    DESIGN II SEE ILLUSTRATION
  • 7
    811678A6 SCREW AND SEAL KIT
    DESIGN II SEE ILLUSTRATION
    SCREW AND SEAL KIT
    DESIGN II SEE ILLUSTRATION
  • 8
    811227 PUMP
    DESIGN II SEE ILLUSTRATION
    PUMP
    DESIGN II SEE ILLUSTRATION
  • 9
    811225 MANIFOLD ASSEMBLY
    DESIGN II SEE ILLUSTRATION
    MANIFOLD ASSEMBLY
    DESIGN II SEE ILLUSTRATION
  • 10
    10-813436 SCREW KIT
    SCREW KIT
  • 11
    813437 DRIVE SHAFT
    DRIVE SHAFT
  • 12
    813438 SCREW AND DOWEL PIN KIT
    SCREW AND DOWEL PIN KIT
  • 13
    25-813439A3 SEAL KIT
    SEAL KIT
  • 14
    813434A1 RESERVOIR
    RESERVOIR
  • 15
    22-8134351 PLUG KIT
    PLUG KIT
  • 16
    893929A01 RELIEF VALVE KIT
    RELIEF VALVE KIT
  • 17
    84-811698 WIRING HARNESS
    WIRING HARNESS
  • 18
    813445 RESERVOIR CAP KIT
    RESERVOIR CAP KIT
  • 19
    10-813446 SCREW-CAP
    SCREW-CAP
  • 20
    813447 MOTOR KIT
    MOTOR KIT
  • 21
    813448 END CAP
    END CAP
  • 22
    813449A1 ARMATURE
    ARMATURE
  • 23
    12-813450 THRUST WASHER KIT
    THRUST WASHER KIT
  • 24
    813451 SHELL AND MAGNET KIT
    SHELL AND MAGNET KIT
  • 25
    813452 END FRAME KIT
    END FRAME KIT
  • 26
    10-813453 BOLT AND NUT KIT
    BOLT AND NUT KIT
  • 27
    17-19607 PIN
    PIN
  • 28
    17-821539 GROOVE PIN
    GROOVE PIN
  • -
    854472A3 TRIM PUMP, COMPLETE
    (INCLUDES ALL PARTS ON THIS PAGE)
    TRIM PUMP, COMPLETE
    (INCLUDES ALL PARTS ON THIS PAGE)
  • 1
    19-45907 PLUG-FLYWHEEL
    PLUG-FLYWHEEL
  • 2
    11-22339 NUT
    NUT
  • 3
    12-33001 WASHER
    WASHER
  • 4
    398-832074A6 STATOR
    (MANUAL) USA-S/N-0D055047 & BELOW BEL-S/N-9665164 & BELOW
    STATOR
    (MANUAL) USA-S/N-0D055047 & BELOW BEL-S/N-9665164 & BELOW
  • 4
    398-832075A20 STATOR
    (ELECTRIC) USA-S/N-0D055047 & BELOW BEL-S/N-9665164 & BELOW
    STATOR
    (ELECTRIC) USA-S/N-0D055047 & BELOW BEL-S/N-9665164 & BELOW
  • 5
    248-8722A16 FLYWHEEL
    (MANUAL) USA-S/N-0D055047 & BELOW BEL-S/N-9665164 & BELOW
    FLYWHEEL
    (MANUAL) USA-S/N-0D055047 & BELOW BEL-S/N-9665164 & BELOW
  • 5
    248-8722A17 FLYWHEEL
    (ELECTRIC) USA-S/N-0D055047 & BELOW BEL-S/N-9665164 & BELOW
    FLYWHEEL
    (ELECTRIC) USA-S/N-0D055047 & BELOW BEL-S/N-9665164 & BELOW
  • 4
    398-832074A6 STATOR
    (MANUAL) BEL-S/N-9665165 & UP USA -S/N-0D055048 & UP
    STATOR
    (MANUAL) BEL-S/N-9665165 & UP USA -S/N-0D055048 & UP
  • 4
    398-832075A20 STATOR
    (ELECTRIC-STAMPED 398-818535A3 OR A13) BEL-S/N-9665165 & UP USA -S/N-0D055048 & UP
    STATOR
    (ELECTRIC-STAMPED 398-818535A3 OR A13) BEL-S/N-9665165 & UP USA -S/N-0D055048 & UP
  • 4
    398-9710A45 STATOR
    (ELECTRIC) BEL-S/N-9665165 & UP USA -S/N-0D055048 & UP
    STATOR
    (ELECTRIC) BEL-S/N-9665165 & UP USA -S/N-0D055048 & UP
  • 5
    248-8722A13 FLYWHEEL
    (MANUAL) BEL-S/N-9665165 & UP USA -S/N-0D055048 & UP
    FLYWHEEL
    (MANUAL) BEL-S/N-9665165 & UP USA -S/N-0D055048 & UP
  • 5
    248-8722T19 FLYWHEEL
    (ELECTRIC) BEL-S/N-9665165 & UP USA -S/N-0D055048 & UP
    FLYWHEEL
    (ELECTRIC) BEL-S/N-9665165 & UP USA -S/N-0D055048 & UP
  • 6
    10-32417 SCREW
    SCREW
  • 7
    50-88755 RATCHET
    (MANUAL)
    RATCHET
    (MANUAL)
  • 8
    10-68997 SCREW
    SCREW
  • 9
    10-75840 SCREW (7/8 IN.)
    SCREW (7/8 IN.)
  • 10
    96452A5 TRIGGER ASSEMBLY
    (ELECTRIC)
    TRIGGER ASSEMBLY
    (ELECTRIC)
  • 11
    50-898265005 STARTER MOTOR
    (ELECTRIC)
    STARTER MOTOR
    (ELECTRIC)
  • 12
    8M0043376 STOP-RUBBER-STARTER MOTOR
    (ELECTRIC)
    STOP-RUBBER-STARTER MOTOR
    (ELECTRIC)
  • 13
    23-8M0034918 COLLAR-RUBBER-STARTER MOTOR MOUNT
    (ELECTRIC)
    COLLAR-RUBBER-STARTER MOTOR MOUNT
    (ELECTRIC)
  • 14
    84-88439A20 WIRE-STARTER MOTOR/SOIENOID
    (ELECTRIC)
    WIRE-STARTER MOTOR/SOIENOID
    (ELECTRIC)
  • 15
    11-64015 NUT-WIRE TO STARTER MOTOR (1/4-20)
    (ELECTRIC)
    NUT-WIRE TO STARTER MOTOR (1/4-20)
    (ELECTRIC)
  • 16
    84-93388A14 WIRE-STARTER MOTOR/BRACKET (BLACK)
    (ELECTRIC)
    WIRE-STARTER MOTOR/BRACKET (BLACK)
    (ELECTRIC)
  • 17
    10-69035 SCREW-WIRE TO STARTER MOTOR (5/8 IN.)
    (ELECTRIC)
    SCREW-WIRE TO STARTER MOTOR (5/8 IN.)
    (ELECTRIC)
  • 18
    84-88439A4 BATTERY CABLE
    (BLACK-NEGATIVE) (ELECTRIC)
    BATTERY CABLE
    (BLACK-NEGATIVE) (ELECTRIC)
  • 18
    84-88439A3 BATTERY CABLE
    (RED-POSITIVE) (ELECTRIC)
    BATTERY CABLE
    (RED-POSITIVE) (ELECTRIC)
  • 19
    23-56774 SPACER
    (ELECTRIC)
    SPACER
    (ELECTRIC)
