FUEL TANK(S-675-00450/L-32875 & BELOW) для Mariner - 60 (2 CYL.) EL-675-30101 THRU EL-675-304180

  • №
    Артикул
    Название
  • 0-1
    1651-8612M GEAR HOUSING ASSEMBLY (SHORT SHAFT)
    GEAR HOUSING ASSEMBLY (SHORT SHAFT)
  • 0-1
    1651-8613M GEAR HOUSING ASSEMBLY (LONG SHAFT)
    GEAR HOUSING ASSEMBLY (LONG SHAFT)
  • 1
    1651-7971M GEAR HOUSING ASSEMBLY
    GEAR HOUSING ASSEMBLY
  • 2
    81449M GUIDE, SEAL
    GUIDE, SEAL
  • 3
    22-81924M PLUG
    PLUG
  • 4
    27-81987 GASKET
    GASKET
  • 5
    81445M COVER, GEAR HOUSING
    COVER, GEAR HOUSING
  • 6
    25-82281M O-RING, COVER TO GEAR HOUSING
    O-RING, COVER TO GEAR HOUSING
  • 7
    26-82257M SEAL, Oil, GEAR HOUSING COVER
    SEAL, Oil, GEAR HOUSING COVER
  • 8
    10-826957M BOLT
    BOLT
  • 9
    12-82214M WASHER
    WASHER
  • 10
    81408M ROD, SHIFT - LOWER
    ROD, SHIFT - LOWER
  • 11
    53-82334M RING, Snap
    RING, Snap
  • 12
    81409M CAM, SHIFT
    CAM, SHIFT
  • 13
    45-81451M DRIVESHAFT (SHORT SHAFT)
    DRIVESHAFT (SHORT SHAFT)
  • 13
    45-81452M DRIVESHAFT (LONG SHAFT)
    DRIVESHAFT (LONG SHAFT)
  • 14
    28-81912M KEY, DRIVESHAFT TO IMPELLER
    KEY, DRIVESHAFT TO IMPELLER
  • 15
    31-82319T BEARING, DRIVESHAFT
    BEARING, DRIVESHAFT
  • 16
    15-81467M SHIM, DRIVESHAFT BEARING (.05MM)
    SHIM, DRIVESHAFT BEARING (.05MM)
  • 16
    15-81468M SHIM, DRIVESHAFT BEARING (.08MM)
    SHIM, DRIVESHAFT BEARING (.08MM)
  • 16
    15-19148002 SHIM, DRIVESHAFT BEARING (.12MM)
    SHIM, DRIVESHAFT BEARING (.12MM)
  • 16
    15-19148004 SHIM, DRIVESHAFT BEARING (.30MM)
    SHIM, DRIVESHAFT BEARING (.30MM)
  • 16
    15-19153M SHIM, DRIVESHAFT BEARING (.50MM)
    SHIM, DRIVESHAFT BEARING (.50MM)
  • 17
    23-81453M SLEEVE, DRIVESHAFT
    SLEEVE, DRIVESHAFT
  • 18
    31-82316T BEARING, NEEDLE- DRIVESHAFT
    BEARING, NEEDLE- DRIVESHAFT
  • 19
    12-81455M BEARING, DRIVESHAFT
    BEARING, DRIVESHAFT
  • 20
    11-81772M NUT, DRIVESHAFT
    NUT, DRIVESHAFT
  • 21
    43-82991M GEAR SET
    GEAR SET
  • 22
    43-84208M GEAR, PINION
    GEAR, PINION
  • 23
    43-84206M GEAR, FORWARD
    GEAR, FORWARD
  • 24
    43-84207M GEAR, REVERSE
    GEAR, REVERSE
  • 25
    15-81456M SHIM, FORWARD GEAR ADJUST (.05MM)
    SHIM, FORWARD GEAR ADJUST (.05MM)
  • 25
    15-81457M SHIM, FORWARD GEAR ADJUST (.08MM)
    SHIM, FORWARD GEAR ADJUST (.08MM)
  • 25
    15-19148003 SHIM, FORWARD GEAR ADJUST (.12MM)
    SHIM, FORWARD GEAR ADJUST (.12MM)
  • 25
    15-19158M SHIM, FORWARD GEAR ADJUST (.30MM)
    SHIM, FORWARD GEAR ADJUST (.30MM)
  • 25
    15-81460M SHIM, FORWARD GEAR ADJUST (.50MM)
    SHIM, FORWARD GEAR ADJUST (.50MM)
  • 26
    31-82320T BEARING, FORWARD GEAR
    BEARING, FORWARD GEAR
  • 27
    52-81473T CLUTCH
    CLUTCH
  • 28
    17-81903M PIN, CLUTCH
    PIN, CLUTCH
  • 29
    81474M RING, CROSS PIN
    RING, CROSS PIN
  • 30
    92643M PLUNGER, SHIFT
    PLUNGER, SHIFT
  • 31
    81475M SLIDE, SHIFT
    SLIDE, SHIFT
  • 32
    24-82091M SPRING, SHIFT
    SPRING, SHIFT
  • 33
    44-92644M SHAFT, PROPELLER
    SHAFT, PROPELLER
  • 34
    12-81837M WASHER, REVERSE GEAR
    WASHER, REVERSE GEAR
  • 35
    15-81462M SHIM, REVERSE GEAR ADJ (.05MM)
    SHIM, REVERSE GEAR ADJ (.05MM)
  • 35
    15-81463M SHIM, REVERSE GEAR ADJ (.08MM)
    SHIM, REVERSE GEAR ADJ (.08MM)
  • 35
    15-19163002 SHIM, REVERSE GEAR ADJ (.12MM)
    SHIM, REVERSE GEAR ADJ (.12MM)
  • 35
    15-19163001 SHIM, REVERSE GEAR ADJ (.30MM)
    SHIM, REVERSE GEAR ADJ (.30MM)
  • 35
    15-19165M SHIM, REVERSE GEAR ADJ (.50MM)
    SHIM, REVERSE GEAR ADJ (.50MM)
  • 36
    12-81461M WASHER, REVERSE GEAR
    WASHER, REVERSE GEAR
  • 37
    30-82296T BEARING, REVERSE GEAR
    BEARING, REVERSE GEAR
  • 38
    25-82289M O-RING, BEARING HOUSING
    O-RING, BEARING HOUSING
  • 39
    81446M CARRIER, Bearing
    CARRIER, Bearing
  • 40
    28-81916M KEY
    KEY
  • 41
    31-82317M BEARING, NEEDLE - PROPELLER SHAFT
    BEARING, NEEDLE - PROPELLER SHAFT
  • 42
    26-854017 SEAL, Oil, PROPELLER SHAFT
    SEAL, Oil, PROPELLER SHAFT
  • 43
    14-81877M WASHER, CLAW
    WASHER, CLAW
  • 44
    11-8M0059031 NUT
    NUT
  • 45
    46-81416M BODY, WATER PUMP
    BODY, WATER PUMP
  • 46
    81419M INSERT, CARTRIDGE
    INSERT, CARTRIDGE
  • 47
    47-97108M IMPELLER, WATER PUMP
    IMPELLER, WATER PUMP
  • 48
    27-81417 GASKET, WATER PUMP
    GASKET, WATER PUMP
  • 49
    81420M OUTER PLATE, CARTRIDGE
    OUTER PLATE, CARTRIDGE
  • 50
    27-81421M GASKET, CARTRIDGE OUTER PLATE
    GASKET, CARTRIDGE OUTER PLATE
  • 51
    46-81422M BASE, WATER PUMP
    BASE, WATER PUMP
  • 52
    27-81418M GASKET
    GASKET
  • 53
    25-82275M O-RING
    O-RING
  • 54
    26-82234M SEAL, Oil, WATER PUMP
    SEAL, Oil, WATER PUMP
  • 55
    17-82354M PIN, DOWEL
    PIN, DOWEL
  • 56
    10-84057M BOLT
    BOLT
  • 57
    10-85277614 BOLT
    BOLT
  • 58
    12-82217M WASHER
    WASHER
  • 59
    26-81426M SEAL, WATER TUBE - UPPER
    SEAL, WATER TUBE - UPPER
  • 60
    81448M SEAL, RUBBER
    SEAL, RUBBER
  • 61
    19166M COVER, WATER INLET - PORT
    COVER, WATER INLET - PORT
  • 62
    19167M COVER, WATER INLET - STARBOARD
    COVER, WATER INLET - STARBOARD
  • 63
    10-82484M SCREW
    SCREW
  • 64
    11-8528165 NUT
    NUT
  • 65
    17-82364M PIN, Dowel
    PIN, Dowel
  • 66
    10-91636M BOLT
    BOLT
  • 67
    13-82218M LOCKWASHER
    LOCKWASHER
  • 68
    10-43103M BOLT
    BOLT
  • 69
    13-82215M LOCKWASHER
    LOCKWASHER
  • 70
    83859T TRIM TAB
    TRIM TAB
  • 71
    10-82801M BOLT
    BOLT
  • 72
    98937M GUIDE, REVERSE ROD
    GUIDE, REVERSE ROD
  • 73
    81410M CAM, REVERSE ROD
    CAM, REVERSE ROD
  • 74
    73345A1 THRUST WASHER
    THRUST WASHER
  • 75
    859935 NUT, PROPELLER
    NUT, PROPELLER
  • 76
    18-95295 PIN, COTTER
    PIN, COTTER
  • 77
    12-81852M WASHER, WATER TUBE
    WASHER, WATER TUBE
  • 78
    32-81424M TUBE, WATER (SHORT SHAFT)
    TUBE, WATER (SHORT SHAFT)
  • 78
    32-81425M TUBE, WATER (LONG SHAFT)
    TUBE, WATER (LONG SHAFT)
  • 79
    25-81989M O-RING, WATER TUBE
    O-RING, WATER TUBE
  • 80
    81428M SET PLATE, WATER TUBE
    SET PLATE, WATER TUBE
  • 81
    10-91772M BOLT
    BOLT
  • 82
    13-82212M LOCKWASHER
    LOCKWASHER
  • 83
    26-81427M SEAL, WATER TUBE - LOWER
    SEAL, WATER TUBE - LOWER
  • 84
    22-8M0121335 PLUG, FLUSH (OPT)
    PLUG, FLUSH (OPT)
  • -
    27-84179M GASKET SET
    GASKET SET
  • -
    84188T REPAIR KIT
    REPAIR KIT
  • 0-1
    1252-6836M TANK ASSEMBLY, Fuel
    TANK ASSEMBLY, Fuel
  • 1
    37-82984M DECAL
    DECAL
  • 2
    81694M CAP, Fuel Tank
    CAP, Fuel Tank
  • 3
    81321M HOUSING, FUEL CONNECTOR
    HOUSING, FUEL CONNECTOR
  • 4
    27-81320M GASKET, HOUSING TO TANK
    GASKET, HOUSING TO TANK
  • 5
    10-83356M SCREW, HOUSING ATTACHING
    SCREW, HOUSING ATTACHING
  • 6
    12-95501M WASHER, HOUSING SCREW
    WASHER, HOUSING SCREW
  • 7
    27-17540M GASKET, HOUSING TO LENS INDICATOR
    GASKET, HOUSING TO LENS INDICATOR
  • 8
    80269M LENS, INDICATOR
    LENS, INDICATOR
  • 9
    80268M BRACKET, INDICATOR
    BRACKET, INDICATOR
  • 10
    10-83523M SCREW, SUPPORT ATTACHING
    SCREW, SUPPORT ATTACHING
  • 11
    81318M INDICATOR
    INDICATOR
  • 12
    81319M FLOAT, INDICATOR
    FLOAT, INDICATOR
  • 0-2
    32-877681Q8 HOSE ASSEMBLY, Fuel
    HOSE ASSEMBLY, Fuel
  • 13
    22-14213Q HOUSING ASSEMBLY
    HOUSING ASSEMBLY
  • 14
    25-82789M O-RING
    O-RING
  • 15
    23-81327M COLLAR, HOSE
    COLLAR, HOSE
  • 16
    89396Q01 PRIMER BULB
    PRIMER BULB
  • 17
    32-94727M HOSE, CONNECTOR HOUSING TO BULB
    HOSE, CONNECTOR HOUSING TO BULB
  • 18
    32-94727M HOSE, BULB TO CONNECTOR
    HOSE, BULB TO CONNECTOR
  • 19
    54-16725M CLAMP, HOSE
    CLAMP, HOSE
