Mount Cradle для Mariner - 275 VERADO (4-STROKE)(6 CYL.) 0T980000 THRU 1B226999

  • №
    Артикул
    Название
  • 1
    8M0109275 SEAL
    SEAL
  • 2
    884887T07 MOUNT CRADLE
    MOUNT CRADLE
  • 3
    8M0060014 SEAL
    SEAL
  • 4
    8M0103708 MOUNT, Rear
    MOUNT, Rear
  • 5
    8M0103365 MOUNT, Front
    MOUNT, Front
  • 6
    10-889745030 SCREW, (M12 x 30)
    SCREW, (M12 x 30)
  • 7
    10-8M0103832 SCREW, (M16 x 90)
    SCREW, (M16 x 90)
  • 8
    25-19565002 GROMMET
    GROMMET
  • 9
    10-40011126 SCREW, (M6 x 13) Stainless Steel
    SCREW, (M6 x 13) Stainless Steel
  • 10
    32-8M0108355 HOSE, (57.00 Inches Bulk), Cut to 35 Inches
    HOSE, (57.00 Inches Bulk), Cut to 35 Inches
  • 11
    22-895797001 FITTING, Telltale
    FITTING, Telltale
  • 12
    54-895851 CLAMP, (8.00 Inches)
    CLAMP, (8.00 Inches)
  • 13
    17-73194 PIN, Roll (.125 x 1.12) (1/8 x 1.12)
    PIN, Roll (.125 x 1.12) (1/8 x 1.12)
  • 14
    880649002 LEVER, Tilt Lock
    LEVER, Tilt Lock
  • 15
    24-47968 SPRING
    SPRING
  • 16
    889540A03 TILT, Lock Clutch
    TILT, Lock Clutch
  • 17
    8M0109693 BRACKET, Tilt Lock
    BRACKET, Tilt Lock
  • 18
    8M0076907 PAD, Tilt Lock
    SN# 1B108510 & Below
    PAD, Tilt Lock
    SN# 1B108510 & Below
  • 18
    8M0076907 PAD, Tilt Lock
    SN# 1B108511 & Up
    PAD, Tilt Lock
    SN# 1B108511 & Up
  • 19
    880650003 SHAFT, Tilt Lock
    SN# 1B073531 & Below
    SHAFT, Tilt Lock
    SN# 1B073531 & Below
  • 19
    880650003 SHAFT, Tilt Lock
    SN# 1B073532 & Up
    SHAFT, Tilt Lock
    SN# 1B073532 & Up
  • 20
    10-889546 SCREW, (M5 x 10)
    SCREW, (M5 x 10)
  • 21
    31-8806641 BEARING, (.625 Inch)
    BEARING, (.625 Inch)
  • 22
    888590002 SENSOR
    SENSOR
  • 23
    10-889547 SCREW, (M5 x 30)
    SCREW, (M5 x 30)
