TRANSMISSION - COUNTERSHAFT для Ktm 300 XC-W - 2017 года выпуска

  • №
    Артикул
    Название
  • 1
    0471170015 CIRCLIP DIN 0471-17X1, 5
    CIRCLIP DIN 0471-17X1, 5
  • 2
    0625062035 BALL BEARING 6203 JR2 C3
    BALL BEARING 6203 JR2 C3
  • 3
    77233020000 STOP DISK 17,2X30X1,3
    STOP DISK 17,2X30X1,3
  • 4
    0405202612 NEEDLE BEARING K 20X26X12
    NEEDLE BEARING K 20X26X12
  • 5
    54833211000 IDLER GEAR 1. G, Z=32
    IDLER GEAR 1. G, Z=32
  • 6
    54833080000 STOP DISC 20,2X30X1
    STOP DISC 20,2X30X1
  • 7
    54833216000 SLIDING GEAR 6.G., Z=20
    SLIDING GEAR 6.G., Z=20
  • 8
    0417024000 CIRCLIP WS24
    CIRCLIP WS24
  • 9
    54833043000 STOP DISC 25X0,8X30X30X7H
    STOP DISC 25X0,8X30X30X7H
  • 10
    54833213000 IDLER GEAR 3.G., Z= 25
    IDLER GEAR 3.G., Z= 25
  • 11
    0405222611 NEEDLE BEAR.K 22X26X10 DIVIDED
    NEEDLE BEAR.K 22X26X10 DIVIDED
  • 12
    54833214000 IDLER GEAR 4.G., Z=23
    IDLER GEAR 4.G., Z=23
  • 13
    54833215000 SLIDING GEAR 5.G., Z=22
    SLIDING GEAR 5.G., Z=22
  • 14
    54833044000 STOP DISC 25X31X1,5
    STOP DISC 25X31X1,5
  • 15
    54833212000 IDLER GEAR 2. G., Z=26
    IDLER GEAR 2. G., Z=26
  • 16
    0405242812 NEDDLE BEAR. K24X28X11,9 DIV.
    NEDDLE BEAR. K24X28X11,9 DIV.
  • 17
    77233110000 COUNTERSHAFT
    COUNTERSHAFT
  • 18
    49030023000 CYL.ROLL BEARING NJ205
    CYL.ROLL BEARING NJ205
  • 19
    0760324571 SHAFT SEAL RING 32X45X7 BSLNBR
    SHAFT SEAL RING 32X45X7 BSLNBR
  • 20
    0770020220 O-RING 25,12X1,78 NBR70
    O-RING 25,12X1,78 NBR70
  • 21
    78133014000 SPACER SLEEVE COUNTER
    SPACER SLEEVE COUNTER
  • 22
    79233029013 SPROCKET 13T
    SPROCKET 13T
  • 23
    59033034000 SPRING WASHER 17,2X40X1,5
    SPRING WASHER 17,2X40X1,5
  • 24
    59033029000 HH COLLAR SCREW M10X18 10.9
    HH COLLAR SCREW M10X18 10.9
  • 99
    00050000983 COUNTER SHAFT REP .KIT 2 STROKE
    COUNTER SHAFT REP .KIT 2 STROKE
