FRONT FORK DISASSEMBLED для Ktm 350 XCFW SIX DAYS - 2016 года выпуска

  • №
    Артикул
    Название
  • 1
    48601326S1 AXLE CLAMP L/S WITH INNER TUBE
    AXLE CLAMP L/S WITH INNER TUBE
  • 2
    48601327S1 AXLE CLAMP R/S WITH INNER TUBE
    AXLE CLAMP R/S WITH INNER TUBE
  • 3
    0025080256 HH COLLAR SCREW M8X25
    HH COLLAR SCREW M8X25
  • 4
    48601050E SCREW CAP M51X1,5 REB. KPL.
    SCREW CAP M51X1,5 REB. KPL.
  • 5
    48601116E SCREW CAP M51X1,5 CPL.
    SCREW CAP M51X1,5 CPL.
  • 6
    48600736 OUTER TUBE L577 D54/60MM 2L
    OUTER TUBE L577 D54/60MM 2L
  • 7
    R14063 FORK REP . KIT 48MM OFFROAD
    FORK REP . KIT 48MM OFFROAD
  • 8
    R14040 GASKET KIT CPL.
    GASKET KIT CPL.
  • 9
    91410100S SPRING 4,0N/MM SET D=4,9MM
    SPRING 4,0N/MM SET D=4,9MM
  • 9
    91410101S SPRING 4,2N/MM SET D=4,9MM
    SPRING 4,2N/MM SET D=4,9MM
  • 9
    91410102S SPRING 4,4N/MM SET D=4,9MM
    SPRING 4,4N/MM SET D=4,9MM
  • 9
    91410103S SPRING 4,6N/MM SET D=4,9MM
    SPRING 4,6N/MM SET D=4,9MM
  • 9
    91410104S SPRING 4,8N/MM SET D=4,9MM
    SPRING 4,8N/MM SET D=4,9MM
  • 10
    R14033 SCREW CAP SMALL PART KIT
    SCREW CAP SMALL PART KIT
  • 11
    48601035S SPRING GUIDE CPL.
    SPRING GUIDE CPL.
  • 12
    48601343S PISTON ROD CPL.
    PISTON ROD CPL.
  • 13
    48600382 SHUTTLE VALVE SPRING C=0,4
    SHUTTLE VALVE SPRING C=0,4
  • 14
    R14056 TAP KIT
    TAP KIT
  • 15
    48601390S3 ADAPTER D20 COMPR. CPL.
    ADAPTER D20 COMPR. CPL.
  • 16
    R14035 SCREW SLEEVE KIT
    SCREW SLEEVE KIT
  • 17
    4861025S1 CONTROL V AL VE D21 CPL.
    CONTROL V AL VE D21 CPL.
  • 18
    48601315S4 PRESSURE T ANK CPL.
    PRESSURE T ANK CPL.
  • 19
    48601031S1 TUBE L403 + ADAPTER
    TUBE L403 + ADAPTER
  • 20
    48601522S SCREW CAP CPL.
    SCREW CAP CPL.
  • 97
    T511 SILICONE GREASE F. DUST STRI
    SILICONE GREASE F. DUST STRI
  • 98
    48601166S1 FORK OIL SAE4 5L
    FORK OIL SAE4 5L
  • 99
    R24002 O-RING SET 4CS
    O-RING SET 4CS
