KICK STARTER для Ktm 200 XC-W - 2014 года выпуска

  • №
    Артикул
    Название
  • 30
    50333030000 STOP DISK 17,2X24X1
    STOP DISK 17,2X24X1
  • 31
    0471170010 CIRCLIP DIN0471-17X1
    CIRCLIP DIN0471-17X1
  • 32
    0988162210 THRUST WASHER DIN0988-16X22X1
    THRUST WASHER DIN0988-16X22X1
  • 38
    50333038100 SPACER BUSHING 16X23X26X6,1
    SPACER BUSHING 16X23X26X6,1
  • 39
    0025080206 HH COLLAR SCREW M8X20 TX40
    HH COLLAR SCREW M8X20 TX40
  • 40
    0025060166 HH COLLAR SCREW M6X16 TX30
    HH COLLAR SCREW M6X16 TX30
  • 41
    50333041000 STOP DISC 17,2X26X1 B
    STOP DISC 17,2X26X1 B
  • 50
    50333050000 KICKSTARTER SHAFT
    KICKSTARTER SHAFT
  • 51
    50333051026 KICKSTART.GEAR 26-T
    KICKSTART.GEAR 26-T
  • 52
    50333052000 KICKSTARTER RATCHET
    KICKSTARTER RATCHET
  • 53
    50333053127 INTERMEDIATE GEAR 27-T
    INTERMEDIATE GEAR 27-T
  • 54
    50333054000 KICKSTARTER SPRING 2,6MM
    KICKSTARTER SPRING 2,6MM
  • 55
    50333055000 DRIVING HUB
    DRIVING HUB
  • 56
    50333056000 SPRING 1,4MM
    SPRING 1,4MM
  • 69
    50333069000 STOP MET.SHEET 4MM
    STOP MET.SHEET 4MM
  • 70
    50333070244 KICK STARTER CPL.
    KICK STARTER CPL.
  • 71
    0760172870 SHAFT SEAL RING 17X28X7 B
    SHAFT SEAL RING 17X28X7 B
  • 75
    50333075000 WASHER 8,2X22X4,5
    WASHER 8,2X22X4,5
