MONOSHOCK для Ktm 990 ADVENTURE R - 2011 года выпуска

  • №
    Артикул
    Название
  • 1
    12187K0901 MONOSHOCK
    MONOSHOCK
  • 2
    50180412S2 MONOSHOCK UPPER PART CPL.
    MONOSHOCK UPPER PART CPL.
  • 3
    50180358S5 MONOSHOCK LOWER PART
    MONOSHOCK LOWER PART
  • 4
    60004016000 SCREW M14X1,5 L=55MM
    SCREW M14X1,5 L=55MM
  • 5
    60004017000 SCREW M14X1,5 L=73MM
    SCREW M14X1,5 L=73MM
  • 11
    50180366 ADAPTOR BUSH KGW 14X24
    ADAPTOR BUSH KGW 14X24
  • 12
    R12012 REP. KIT BEAR./SEAL UP.
    REP. KIT BEAR./SEAL UP.
  • 13
    R12013 REP.KIT BEAR/SEAL LOWER ADV
    REP.KIT BEAR/SEAL LOWER ADV
  • 15
    50180365 ADAPTOR BUSH KGW D=32 14X32
    ADAPTOR BUSH KGW D=32 14X32
  • 21
    50180095 BLEED PLUG R 1/8
    BLEED PLUG R 1/8
  • 30
    50180213S4 DCC-COMPR.DAMP.CONTROL CPL.
    DCC-COMPR.DAMP.CONTROL CPL.
  • 40
    50180465 SPRING RETAINER D=78, H=35
    SPRING RETAINER D=78, H=35
  • 41
    50180133 CIRCLIP 50X1,5
    CIRCLIP 50X1,5
  • 42
    50180081 SPRING GUIDANCE L=40
    SPRING GUIDANCE L=40
  • 43
    50180114 SPACER RING FOR SPRING
    SPACER RING FOR SPRING
  • 44
    91210090S SPRING 140-225 D=14,25 (62)
    SPRING 140-225 D=14,25 (62)
  • 44
    91210092S SPRING 150-225 D=14,5 (62)
    SPRING 150-225 D=14,5 (62)
  • 44
    91210093S SPRING 130-225 D=14 (62)
    SPRING 130-225 D=14 (62)
  • 45
    50180402 INTERM.RING SPRING RET. H=3,5
    INTERM.RING SPRING RET. H=3,5
  • 46
    50180352 O-RING VITON 66,27X3,53
    O-RING VITON 66,27X3,53
  • 47
    50180463S SPRING RET. D=80 W. O-RING
    SPRING RET. D=80 W. O-RING
  • 48
    50180273 CIRCLIP 58,2X2
    CIRCLIP 58,2X2
  • 51
    46811208 RUBBER CAP "DO NOT OPEN"
    RUBBER CAP "DO NOT OPEN"
  • 52
    36120151 SCREW PLUG M5X6
    SCREW PLUG M5X6
  • 53
    46810893 O-RING NBR 5,28X1,78
    O-RING NBR 5,28X1,78
  • 55
    50180276 BUMP RUBBER WP60 D=18-26
    BUMP RUBBER WP60 D=18-26
  • 56
    50180487 COVER D=50
    COVER D=50
  • 62
    50180434S ADJUSTING SCREW REBOUND TRAVEL
    ADJUSTING SCREW REBOUND TRAVEL
  • 98
    50180751S1 SHOCK ABSORBER FLUID 5 LT
    SHOCK ABSORBER FLUID 5 LT
  • 99
    R12008 REPAIR-KIT GASKET
    REPAIR-KIT GASKET
