IGNITION SYSTEM для Ktm 250 SX-F - 2008 года выпуска

  • №
    Артикул
    Название
  • 1
    7703000220025 IGNITION COVER
    IGNITION COVER
  • 2
    77030040000 IGNITION COVER GASKET
    IGNITION COVER GASKET
  • 3
    77039004000 STATOR 4K3-A
    STATOR 4K3-A
  • 4
    77039005000 FLYWHEEL
    FLYWHEEL
  • 5
    59039034000 PULSER COIL KOKUSAN 4K3-A/B
    PULSER COIL KOKUSAN 4K3-A/B
  • 6
    77039031600 CDI UNIT
    CDI UNIT
  • 8
    59039090100 SPARK PLUG CONNECT. VD05EG
    SPARK PLUG CONNECT. VD05EG
  • 9
    77039093000 SPARK PLUG NGK CR9EKB
    SPARK PLUG NGK CR9EKB
  • 10
    77030002050 WIRE RETAINING BRACKET
    WIRE RETAINING BRACKET
  • 11
    0015060083 HH COLLAR SCREW M 6X8
    HH COLLAR SCREW M 6X8
  • 12
    59439032100 WIRING HARNESS FOR CDI EXC
    WIRING HARNESS FOR CDI EXC
  • 16
    59039006000 IGNITIONCOIL KOKUSAN 4K3-A/B
    IGNITIONCOIL KOKUSAN 4K3-A/B
  • 20
    44011076100 CABLE TIE 100/2,5MM BLACK
    CABLE TIE 100/2,5MM BLACK
  • 29
    49030090000 DOWEL 9,8 X 7 X 10
    DOWEL 9,8 X 7 X 10
  • 30
    0015060253 HH COLLAR SCREW M 6X25
    HH COLLAR SCREW M 6X25
  • 31
    0015060303 HH COLLAR SCREW M 6X30
    HH COLLAR SCREW M 6X30
  • 33
    0912050253 AH SCREW DIN0912-M 5X25
    AH SCREW DIN0912-M 5X25
  • 34
    0015050163 HH COLLAR SCREW M 5X16
    HH COLLAR SCREW M 5X16
  • 35
    0024060206 HH COLLAR SCREW M6X20
    HH COLLAR SCREW M6X20
  • 36
    0025060166 HH COLLAR SCREW M6X16
    HH COLLAR SCREW M6X16
  • 37
    0025060206 HH COLLAR SCREW M6X20
    HH COLLAR SCREW M6X20
