SIDE - CENTER STAND для Ktm 990 Adventure Euro - 2006 года выпуска
-
№АртикулНазвание
-
16010302310030 SIDE STAND L=302MMSIDE STAND L=302MM
-
3*62503027100 SCREW F. SIDE STAND M10X31,2SCREW F. SIDE STAND M10X31,2
-
4*61003028001 SCREW SIDE STAND SPRINGSCREW SIDE STAND SPRING
-
6*61003024000 SPRING L=116 MMSPRING L=116 MM
-
760003026000 SIDE STAND BRACKETSIDE STAND BRACKET
-
80015100303 HH COLLAR SCREW M10X30HH COLLAR SCREW M10X30
-
9*60103028000 SIDE STAND PICKUPSIDE STAND PICKUP
-
100015100243 HH COLLAR SCREW M10X24HH COLLAR SCREW M10X24
-
11*61011045000 SIDE STAND SWITCHSIDE STAND SWITCH
-
12*60103029000 SUPPORT F.SIDE STAND SWITCHSUPPORT F.SIDE STAND SWITCH
-
13*0084040123 CYL.HEAD SCREW DIN84A M4X12CYL.HEAD SCREW DIN84A M4X12
-
14*0985040003 SELF LOCKING NUT DIN0985-M 4SELF LOCKING NUT DIN0985-M 4
-
15*60103029050 MAGNET HOLDER ADV.MAGNET HOLDER ADV.
-
16*0015060123 HH COLLAR SCREW M 6X12HH COLLAR SCREW M 6X12
-
22*6000302240030 CENTER STAND L=333MMCENTER STAND L=333MM
-
2360003030000 SPRING FOR CENTER STANDSPRING FOR CENTER STAND
-
2460003022115 SPRING TENSIONERSPRING TENSIONER
-
250125080003 WASHER DIN0125-A 8,4WASHER DIN0125-A 8,4
-
260015080303 HH COLLAR SCREW M 8X30HH COLLAR SCREW M 8X30
-
2756503093000 SPECIAL SCREW M10X55SPECIAL SCREW M10X55
-
280125100003 WASHER DIN0125-A10,5WASHER DIN0125-A10,5
-
2960003022020 BEARING BUSH CENTER STANDBEARING BUSH CENTER STAND
-
3060003022021 SPACER 10X16X38 MMSPACER 10X16X38 MM
