SPEEDOMETER для Ktm 640 SUPERMOTO BLUE CHASSIS - 2005 года выпуска

  • №
    Артикул
    Название
  • 1
    58614061000 SPEEDOMETER BRACKET MIDDLE
    SPEEDOMETER BRACKET MIDDLE
  • 2
    58614062000 SPEEDOMETER BRACKET L/S
    SPEEDOMETER BRACKET L/S
  • 3
    58614063000 SPEEDOMETER BRACKET R/S
    SPEEDOMETER BRACKET R/S
  • 4
    0016050121 SCREW
    SCREW
  • 5
    58214069051 RUBBER GROMMET 16X10,8X3
    RUBBER GROMMET 16X10,8X3
  • 6
    0021050003 WASHER DIN9021-A 5,3
    WASHER DIN9021-A 5,3
  • 7
    0985050003 SELF LOCKING NUT DIN0985-M 5
    SELF LOCKING NUT DIN0985-M 5
  • 8
    0014060103 HH COLLAR SCREW M 6X10 WS=8
    HH COLLAR SCREW M 6X10 WS=8
  • 9
    60014069100 DIGITAL SPEEDOMETER
    DIGITAL SPEEDOMETER
  • 10
    58214069150 SPEEDOMETER SENSOR ADV.
    SPEEDOMETER SENSOR ADV.
  • 11
    0084040083 CYL.HEAD SCREW DIN0084-M 4X8 A
    CYL.HEAD SCREW DIN0084-M 4X8 A
  • 12
    55011022100 CLAMP D=6/8MM, BLACK
    CLAMP D=6/8MM, BLACK
  • 16
    58411066100 IGNITION LOCK
    IGNITION LOCK
  • 17
    58411066244 IGNITION LOCK+TANK PLUG
    IGNITION LOCK+TANK PLUG
  • 18
    0985040123 FLAT HEAD SCREW DIN7985-M 4X12
    FLAT HEAD SCREW DIN7985-M 4X12
  • 19
    40011166100 KEY BLANK
    KEY BLANK
  • 20
    60014068000 DAMPING RING TACHOMETER
    DAMPING RING TACHOMETER
  • 21
    31008060000 RUBBER SLEEVE D=8MM OPEN
    RUBBER SLEEVE D=8MM OPEN
