COOLING SYSTEM для Ktm 200 EXC - 2005 года выпуска

  • №
    Артикул
    Название
  • 7
    50335007000 RADIATOR L/S NATURE 145286)
    RADIATOR L/S NATURE 145286)
  • 8
    50335008000 RADIATOR R/S NATURE (45285)
    RADIATOR R/S NATURE (45285)
  • 9
    59035009000 RADIAL CAP 20,3PS1 (1,4BAR)
    RADIAL CAP 20,3PS1 (1,4BAR)
  • 10
    31007107001 PVC-HOSE 6X9 MM PER METRE
    PVC-HOSE 6X9 MM PER METRE
  • 13
    54835013044 THERMOSTAT 55°C CPL.
    THERMOSTAT 55°C CPL.
  • 15
    0770320020 0-RING 32,00X2,00
    0-RING 32,00X2,00
  • 16
    0016040183 SCREW FOR PLASTIC 0=4X18
    SCREW FOR PLASTIC 0=4X18
  • 17
    54835017000 THERMOSTAT 55°C
    THERMOSTAT 55°C
  • 18
    54835018000 T-CONNECTOR 23/23/12,5
    T-CONNECTOR 23/23/12,5
  • 19
    58335099000 HOSE CLAMP GEM/ ID-16
    HOSE CLAMP GEM/ ID-16
  • 20
    10001020000 HOSE CLAMP GEMI 16-27
    HOSE CLAMP GEMI 16-27
  • 23
    50303089000 ANGEL PIECE
    ANGEL PIECE
  • 24
    54835024000 RADIATOR HOSE 10X17
    RADIATOR HOSE 10X17
  • 25
    56535025001 RADIATOR HOSE 18X25 PER METRE
    RADIATOR HOSE 18X25 PER METRE
  • 26
    54835026033 RADIATOR HOSE W THERMOSTAT
    RADIATOR HOSE W THERMOSTAT
  • 27
    50335027000 RADIATOR HOSE 18X25 (WATER PUMP - RADIATOR)
    RADIATOR HOSE 18X25 (WATER PUMP - RADIATOR)
  • 28
    54835028000 RADIATOR HOSE 18X25
    RADIATOR HOSE 18X25
  • 34
    54635034200 RAD. PROTECT.L/S COLORLESS
    RAD. PROTECT.L/S COLORLESS
  • 34
    5463503420004 RADIATOR PROTECTOR US ORANGE
    RADIATOR PROTECTOR US ORANGE
  • 35
    54635134200 RAD. PROTECT.R/S COLORLESS
    RAD. PROTECT.R/S COLORLESS
  • 35
    5463513420004 RADIATOR PROTECTOR R/S ORANGE
    RADIATOR PROTECTOR R/S ORANGE
  • 39
    44011076200 CABLE TIE200/3,6MM BLACK
    CABLE TIE200/3,6MM BLACK
  • 40
    41001052000 RUBBER SLEEVE D=12MM
    RUBBER SLEEVE D=12MM
  • 41
    0021060003 WASHER DIN9021-A 6,4
    WASHER DIN9021-A 6,4
  • 42
    0015060123 HH COLLAR SCREW M 6X12 WS=8
    HH COLLAR SCREW M 6X12 WS=8
