CARBURETOR KEIHIN PWK 38-5 AG для Ktm 250 SX - 2004 года выпуска`

№

Артикул

Название
1

54831001044 CARBURETOR PWK38-5 AG

CARBURETOR PWK38-5 AG

121 370 ₽
7

54531607038 IDLE JET 38 KEIHIN

IDLE JET 38 KEIHIN

3 300 ₽
7

54531607040 IDLE JET 40 KEIHIN

IDLE JET 40 KEIHIN

3 210 ₽
7

54531607042 IDLE JET 42 KEIHIN

IDLE JET 42 KEIHIN

3 300 ₽
7

54531607045 IDLE JET 45 KEIHIN

IDLE JET 45 KEIHIN

3 240 ₽
7

54531607048 IDLE JET 48 KEIHIN

IDLE JET 48 KEIHIN

3 130 ₽
7

54531607050 IDLE JET 50 KEIHIN

IDLE JET 50 KEIHIN

3 100 ₽
8

57331008000 ARM PIN FLOAT

ARM PIN FLOAT

470 ₽
9

57331009000 FLOAT CPL.

FLOAT CPL.

16 090 ₽
10

54831010000 GASKET FLOAT CHAMBER

GASKET FLOAT CHAMBER

2 860 ₽
11

54831011000 FLOAT CHAMBER PWK38-S AG

FLOAT CHAMBER PWK38-S AG

20 620 ₽
12

54531612100 RETAINING PLATE FOR BLEEDER

RETAINING PLATE FOR BLEEDER

590 ₽
14

0016040163 HH COLLAR SCREW M 4X16 WS=6

HH COLLAR SCREW M 4X16 WS=6

290 ₽
15

54531615000 SPRING FOR ADJUSTMENT SCREW

SPRING FOR ADJUSTMENT SCREW

620 ₽
17

54531617000 ADJUSTMENT SCREW

ADJUSTMENT SCREW

2 080 ₽
18

54631118000 SPRING

SPRING

2 630 ₽
19

54631219100 ADJUSTMENT SCREW M 5

ADJUSTMENT SCREW M 5

4 590 ₽
20

54631020000 FLOAT VALVE CPL. PWK 38 AG PJ

FLOAT VALVE CPL. PWK 38 AG PJ

8 470 ₽
21

54531621000 CLAMP

CLAMP

880 ₽
23

54531623155 MAIN JET 155 KEIHIN

MAIN JET 155 KEIHIN

3 210 ₽
23

54531623158 MAIN JET 158 KEIHIN

MAIN JET 158 KEIHIN

3 300 ₽
23

54531623162 MAIN JET 162 KEIHIN

MAIN JET 162 KEIHIN

3 420 ₽
23

54531623165 MAIN JET 165 KEIHIN

MAIN JET 165 KEIHIN

3 480 ₽
23

54531623168 MAIN JET 168 KEIHIN

MAIN JET 168 KEIHIN

3 540 ₽
23

54531623170 MAIN JET 170 KEIHIN

MAIN JET 170 KEIHIN

3 450 ₽
23

54531623172 MAIN JET 172 KEIHIN

MAIN JET 172 KEIHIN

3 450 ₽
23

54531623175 MAIN JET 175 KEIHIN

MAIN JET 175 KEIHIN

3 450 ₽
23

54531623178 MAIN JET 178 KEIHIN

MAIN JET 178 KEIHIN

3 660 ₽
25

54831025000 SPECIAL-AH-SCREW M 4X12

SPECIAL-AH-SCREW M 4X12

850 ₽
26

54831029000 THROTTLE CABLE HOLDER M6X0,75

THROTTLE CABLE HOLDER M6X0,75

3 770 ₽
27

54831027000 CARBURETOR COVER PWK38-S AG

CARBURETOR COVER PWK38-S AG

12 730 ₽
28

54831028000 GASKET FOR CARBURETOR COVER

GASKET FOR CARBURETOR COVER

2 100 ₽
29

54531629000 CLIP FOR JET NEEDLE

CLIP FOR JET NEEDLE

680 ₽
30

54831030000 SLIDING SPRING

SLIDING SPRING

2 690 ₽
31

54631231000 SPRING CAP

SPRING CAP

2 860 ₽
32

54631232000 NIPPLE

NIPPLE

10 460 ₽
34

54531636005 JET NEEDLE NOZ E KEIHIN

JET NEEDLE NOZ E KEIHIN

5 520 ₽
34

54531636006 JET NEEDLE NOZ F KEIHIN

JET NEEDLE NOZ F KEIHIN

5 550 ₽
34

54531636007 JET NEEDLE NOZ G KEIHIN

JET NEEDLE NOZ G KEIHIN

5 550 ₽
34

54531636008 JET NEEDLE NOZ H KEIHIN

JET NEEDLE NOZ H KEIHIN

5 460 ₽
34

54731134000 JET NEEDLE KEIHIN N3EG

JET NEEDLE KEIHIN N3EG

3 770 ₽
34

54731034900 JET NEEDLE KEIHIN N3EW

JET NEEDLE KEIHIN N3EW

3 620 ₽
35

54631235106 THROTTLE VALVE 65 KEIHIN

THROTTLE VALVE 65 KEIHIN

64 130 ₽
45

54631245000 STARTER PISTON CPL.

STARTER PISTON CPL.

24 300 ₽
46

54531696000 CLAMP 6 MM

CLAMP 6 MM

590 ₽
47

31007007101 PVC-HOSE 4X6MM

PVC-HOSE 4X6MM

760 ₽
48

52031137001 PVC-HOSE 3X5MM

PVC-HOSE 3X5MM

1 000 ₽
49

57331014000 HOLDING BOLT

HOLDING BOLT

4 790 ₽
50

0770180230 O-RING 18,00X2,30 NBR 70

O-RING 18,00X2,30 NBR 70

640 ₽
52

50331029038 SLIDE STOP L=38MM

SLIDE STOP L=38MM

2 060 ₽
53

0770060018 O-RING 6,00X1,78

O-RING 6,00X1,78

410 ₽
